MBTCP Diagnostics

6.3.1 PCB Diagnostics

The best way to troubleshoot the MBTCP driver is to use ProSoft Configuration
Builder to access the diagnostic capabilities of the gateway through the Ethernet
debug port. For instructions on how to access Diagnostics, see Using
Diagnostics in ProSoft Configuration Builder (page 36).

6.3.2 MBTCP Status Data in Upper Memory

The MBTCP driver has an associated status data area located in the gateway's
upper memory. The Data Map functionality of the gateway can be used to map
this data into the normal user data range of the gateway's database. See Using
the CommonNet Data Map (page 25).
Note that all the status values are initialized to zero (0) at power-up, cold boot
and during warm boot.
MBTCP Server Status Data
The following table lists the addresses in upper memory where status data for
MBTCP servers can be found.
Server Port
2000
502
2001
The content of each server port's status data area is structured the same. The
following table describes the content of each register in the status data area.
Offset
0
1
2
3
4
5
6
7
8
9
ProSoft Technology, Inc.
May 26, 2016
Address Range
6200 through 6209
6210 through 6219
6220 through 6229
Description
Number of Command Requests
Number of Command Responses
Number of Command Errors
Number of Requests
Number of Responses
Number of Errors Sent
Number of Errors Received
Configuration Error Word
Current Error Code
Last Error Code
MBTCP Protocol
User Manual
Page 105 of 218
