PLX3x Series
Ethernet and Serial Gateways

3.1.2 Ethernet Port LEDs

LED
LINK/ACT
100 Mbit

3.1.3 Serial Port LEDs (for Gateways with Serial Ports)

LED
RX
TX
ProSoft Technology, Inc.
May 26, 2016
State Description
Off No physical network connection is detected. No Ethernet
communication is possible. Check wiring and cables.
Solid Green Physical network connection detected. This LED must be
ON solid for Ethernet communication to be possible
Off No activity on the port.
Flashing Amber The Ethernet port is actively transmitting or receiving data.
State Description
Off No activity on the port.
Flashing Green The port is actively receiving data.
Off No activity on the port.
Flashing Amber The port is actively transmitting data.
Diagnostics and Troubleshooting
User Manual
Page 35 of 218
