Monitoring the Device

5420 Series Switch LEDs

The following topics help you monitor the status of the switch/appliance as it is
running.
5420 Series Switch LEDs
ExtremeSwitching 5420 Series front panel port LEDs, as described in the following
table:
Table 19: 5420 Series Port LEDs
LED
SYStem status LED
(Legacy MGMT function)
PSU status LEDs P1/P2
Speed status (SPD), Stacking
status (STK)
Fan status for 5420F
Fan module status for 5420M
on page 91
Color/State
Green Flash slowly POST Passed,
Green Blinking
Amber Blinking
Green
Off
Amber Blinking
SPD solid green
STK solid green
All off
Green
Amber Blinking
Green
Amber Blinking
Off
