ExtremeSwitching 5420 Series Overview
The 5420 Series includes the following models:
•
5420F-8W-16P-4XE Switch Features
•
5420F-24P-4XE Switch Features
•
5420F-24S-4XE Switch Features
•
5420F-24T-4XE Switch Features
•
5420F-16MW-32P-4XE Switch Features
•
5420F-16W-32P-4XE Switch Features
•
5420F-48P-4XE Switch Features
•
5420F-48P-4XL Switch Features
•
5420F-48T-4XE Switch Features
•
5420M-24T-4YE Switch Features
•
5420M-24W-4YE Switch Features
•
5420M-16MW-32P-4YE Switch Features
•
5420M-48T-4YE Switch Features
•
5420M-48W-4YE Switch Features
Management
An RJ45 serial console port on the front panel of the 5420 Series switch enables you
to connect a terminal and perform local management. An Ethernet management
port can be used to connect the system to an out-of-band management network
for administration. Alternatively, you can use an Ethernet cable to connect this port
directly to a laptop to view and locally manage the switch configuration. The Ethernet
management port supports 10/100/1000 Mbps speeds.
There is one Micro-B USB console port on the front panel. If the Micro-B USB console
port is connected, it will be selected over the RJ45 console port. The Micro-B USB
console port will disconnect when the switch is rebooted. You can re-connect the port
if needed. When the Micro-B USB console is active, any messages from the switch to
the client terminal will be echoed to both the USB console and the rear panel RJ45
serial port; however, no user input will be accepted from the rear panel port.
Tip
Using a Micro-USB Type B to USB Type A cable, connect the Micro-USB Type B
end to the switch, and the USB Type A end to a laptop or PC and complete the
driver installation steps.
on page 16
on page 17
on page 18
on page 19
on page 20
on page 21
on page 23
on page 24
on page 25
on page 26
on page 27
on page 28
on page 30
on page 31
