INLINE REGULATOR LEAK

20
CLEAN AND LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES
014 NBR70 O-RING C
HPR PISTON R
011 NBR70 O-RING
008 NBR70 O-RING
PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL
REGULATOR PLUG
REGULATOR GASKKET
R
REGULATOR HOUSING
REGULATOR HOUSING
013 NBR70 O-RING
R
LPR PISTON
008 NBR70 O-RING
013 NBR70 O-RING
C
C
011 NBR70 O-RING
014 NBR70 O-RING
EGO LV2
R
R
R
C
C
C
007 NBR70 O-RING
013 NBR70
O-RING
C
R
C
R
(C) = COMMON FAULT (R) = RARE FAULT
REGULATOR HOUSING
4X1 NBR70 O-RING
5X1 NBR70 O-RING
FRAME
R
GASKET
FRAME R
C
R
LV2 BODY R
