SOLENOID / MANIFOLD LEAK
17
CLEAN AND LUBRICATE / CHANGE HIGHLIGHTED SEALS AND FACES
SOLENOID-MANIFOLD
C
GASKET
PLANET ECLIPSE OFFICIAL WORKSHOP MANUAL
MANIFOLD-BODY GASKET
MANIFOLD BODY (GASKET
CHANNEL ON BOTH SIDES)
4X1 NBR70 O-RING
SOLENOID R
EGO LV2
C
R
R
C
R
(C) = COMMON FAULT (R) = RARE FAULT
R
LV2 BODY
