- Page 1 M.2A OOB M.2 Out Of Band Module Compact BMC (cBMC) User’s Manual...
- Page 2 Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be repro- This equipment has been tested and found to comply with the limits for a Class B digital duced in any form or by any means or used to make any transformation/adaptation without the device, pursuant to Part 15 of the FCC rules.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 - Introduction........................ 5 What’s OOB (Out-Of-Band) Management ................5 Key Features ........................... 6 (RPS630) M.2 KEY A cBMC ....................7 Chapter 2 - Getting Started ......................8 Hardware Requirements ......................8 System Requirements ......................8 OOB Normal Boot ........................ - Page 4 About this Manual Static Electricity Precautions This manual can be downloaded from the website. It is quite easy to inadvertently damage your PC, system board, components or devices even before installing them in your system unit. Static electrical discharge can damage computer The manual is subject to change and update without notice, and may be based on editions that components without causing any signs of physical damage.
-
Page 5: Chapter 1 - Introduction
Chapter 1 INTRODUCTION Chapter 1 - Introduction X What’s OOB (Out-Of-Band) Management As Industrial IoT demands rise in recent decades, the number of connected IoT devices drastically grow. However, the personnel responsible for equipment mainte- nance cannot meet the growing numbers of IoT devices; additionally, unexpected factors occur, e.g. the global pandemic. It seems like it is harder to maintain and repair the equipment in a timely manner. -
Page 6: Key Features
► Remote BIOS setup & uefi shell (serial over lan) ► Remote BIOS update SPI-NAND ► Remote BIOS update SOL & DFI USB-Storage ► Remote Recovery OS image (uSD or eMMC) User's Manual | M.2 Out Of Band Module Compact BMC... -
Page 7: Rps630) M.2 Key A Cbmc
Chapter 1 INTRODUCTION X (RPS630) M.2 KEY A cBMC RPS630 User's Manual | M.2 Out Of Band Module Compact BMC... -
Page 8: Chapter 2 - Getting Started
Chapter 2 GETTING STARTED Chapter 2 - Getting Started Please follow the steps to configure M.2A OOB. X OOB Normal Boot X Hardware Requirements Step 1: Make sure the switch 1 & 2 change to off. x86 PC RPS630 x1 LAN Cable x1 x86 PC x1 OOB x1... -
Page 9: Default Password Setting
Chapter 2 GETTING STARTED X Default Password Setting Step 1: Step 2: Install Teraterm. Use a LAN cable to connect one end of the Lan cable to the RPS630 LAN4 After Teraterm is being installed, move the four files from Console Redirection Files folder to and the other end to the Server Lan port. - Page 10 Chapter 2 GETTING STARTED Step 3: (Please note that this setup is only required for the first time use.) Click Priorities - Select Internet Protocol Version 4 (TCP/IPv4) and click Priorities. Setup Lan IP Address - Open Network Status go to Advanced network settings and click Type in the following information, then press OK.
- Page 11 Chapter 2 GETTING STARTED Please type in the information as follows: Step 4: Execute windows Command Prompt. C:\users\user name> : ssh root@192.168.10.100 To run the command prompt: Are you sure you want to continue connecting : yes ■ Pressing Windows key + R key to open "Run" box. Type "cmd" and then click "OK". (This question only appears for the first time log in) ■...
-
Page 12: Remote Control Pc Power On/Off
X Remote Control PC Power On/Off After entering the password, you will see DFI. Then type in /DFI # When it displays you may now start typing in commands for each function. User's Manual | M.2 Out Of Band Module Compact BMC... -
Page 13: Pc Power On/Off Status Check
Chapter 2 GETTING STARTED Turn On/Off PC Remotely PC Power On/Off Status Check After the status check, you can control PC power on/off remotely. Please complete step 4 (p.11) before entering the following command. Please complete step 4 (p.11) before entering the following command. Check the current power On/Off status remotely by typing in following command. -
Page 14: Perform A Timed Force Shutdown
Chapter 2 GETTING STARTED PC Rebooting Perform a Timed Force Shutdown To reboot the PC, please type in the following command. To forcibly shut down the PC, please type in the following command. You will hear a single beep, it means PC rebooted successfully. Please complete step 4 (p.11) before entering the following command. -
Page 15: Remote Hardware Monitor Log (Super I/O)
PCH: CPU Temperature Please complete step 4 (p.11) before entering the following command. ./sio_start_log.sh YYYY-MM-DD hh:mm:ss hours /DFI/sio_log & Shell Script : For example: ./sio_start_log.sh 2023-08-22 09:00:00:00 24 /DFI/sio_log & User's Manual | M.2 Out Of Band Module Compact BMC... -
Page 16: Chapter 3 - Bios
After renaming the file, move file to its corresponding users folder in C drive. Step 3: Open command prompt and type in the command below. scp bios.bin root@192.168.10.100:~/DFI/bios/ Shell Script : Please type in the password (MAC Address) : root@192.168.10.100's password: Enter MAC Address where you can find the sticker loacted on LAN4 of the board. - Page 17 After entering the password, you will see Then type in Enter the following command to start updating BIOS: /DFI/bios #./updatebios.sh bios.bin Shell Script : Note: When you type in MAC address in Command Prompt, it doesn't appear or show up on the screen.
-
Page 18: Remote Bios Update (Via Teraterm)
Chapter 3 REMOTE BIOS UPDATE X Remote BIOS Update (Via Teraterm) Remote BIOS Update (SOL & DFI USB-Storage) Remote BIOS Setup & UEFI shell (Serial Over Lan) User's Manual | M.2 Out Of Band Module Compact BMC... - Page 19 Press “ESC” key ,when system power on. Run SSH command: Please type in the information as follows: • Copy BIOS from local PC to remote OOB module scp AfuEfiU.efi root@192.168.10.100:~/DFI/USB/files scp startup.nsh root@192.168.10.100:~/DFI/USB/files • Login & Update BIOS C:\users\user name> : ssh root@192.168.10.100...
- Page 20 REMOTE BIOS UPDATE Step 3: Step 4: Boot from DFI USB-Storage device &Update BIOS in uefi mode When there is no error message displayed, the BIOS update will be completed successfully. Save & Exit ---> UEFI: DFI USB-Storage Use arrow key to select...
