1.2 Part names

1.2.1 Front camera (main unit) - front view

1.2.2 Front camera (main unit) - rear view

Wi-Fi LED
Indicates the Wi-Fi
connection status.
STATUS LED
Indicates the
recording status.
Insert a memory card to save recordings.
• To format the memory card, press and hold the REC button and Wi-Fi button simultaneously for 3 seconds.
• To factory reset the product, press and hold the REC button and Wi-Fi button simultaneously for 7 seconds.
Front camera lens
Records the front view.
REC button
• Short press: Starts manual recording
• Press and hold for 3 seconds: Turns the audio recording on or off.
Memory card slot
Mount connector
Used to connect the mount.
Speaker
Outputs the voice guide and buzzer
sounds to indicate the product's status.
Wi-Fi button
Press and hold for 3 seconds to connect the
product to a smartphone via Wi-Fi network.
Microphone
Used for voice recording.
Product overview
DC-IN power port
Used to connect the
power cable.
GPS port
Used to connect the
external GPS receiver
(optional).
V-IN input port
Used to connect the
rear camera (optional).
7
