1.2 Part names

1.2.1 Front camera (main unit) - front view

Front camera lens
Records the front view.
Insert a memory card to save recordings.

1.2.2 Front camera (main unit) - rear view

Used to connect the power cable.
Outputs the voice guide and buzzer
sounds to indicate the product's status.
Indicates the operating
status of the product.
Mount connector
Used to connect the mount.
Memory card slot
DC-IN power port
Speaker
Status LED
GPS port
Used to connect the external
GPS receiver (optional) for
additional features.
Wi-Fi button
Press to connect the product to a
smartphone via Wi-Fi network.
REC button
• Short Press: Starts manual recording
• Press and hold for 3 seconds:
Audio recording ON/OFF
• Press and hold for 5 seconds:
Memory card format
Microphone
Used for voice recording.
Product overview
7
