Product overview
Refer to the following table to check the status of the product using the LED indicator.
Category
Error
Connection
Firmware upgrade

1.2.3 Rear camera (optional)

Security LED
Indicates that the video is
being recorded.
Depending on the laws and regulations of the country, the security LED specifications may be different.
8
LED STATUS
OFF
(flickers quickly)
(light on)
OFF
(flickers quickly)
(light on)
(light on)
(flickers slowly)
>
Adhesive mount
Used to fix the rear camera in the vehicle.
Rear camera lens
Records the rear view.
Operation description
Reading SD card.
Cannot read SD card.
Crashed while booting.
Bluetooth/Wi-Fi OFF
Bluetooth is pairing.
Bluetooth/Wi-Fi connected.
Bluetooth/Wi-Fi is resetting.
Firmware is upgrading.
Connection port
Used to connect the
rear camera to the front camera
using a rear camera cable.
