TECHNICAL FEATURES:

Motor
Voltage
Max Absorbed Power
Nominal Thrust
Power Supply
Nominal Input Current
Motor Speed
Maximum Gate Weight
Duty Cycle
Operating Temperature
Solar Panel
Gate Weight
Installation
A. CHECKS BEFORE INSTALLATION
Before proceeding with the installation check the following:
1. The structure of the gate should be suitable for automation.
2. The gate should be supported by upper guides.
3. Mechanical end stoppers must be provided to prevent the gate from running off the track.
4. The foundation should be strong enough to support the operator.
5. There are no cables or pipes in the path of the operator and the gate.
6. Be sure that gate moves freely.
7. There are no obstacles in the moving gate area.
8. The operator is not in a position where it can be easily or accidently damaged by passing
vehicles.
9. The 2 x limit magnets should have different marking on them. One should have a
other should have a
magnets can be installed on either side (open or close). Please see the diagram below to locate
the marking on the magnets.
24Volts DC motor
60% over 12 min
670 x 570 x 35 mm
Up to 900Kg on level ground
.You cannot use the limit magnets if they have the same marking. The
AXIOM SLIDING GATE KIT USER MANUAL
iS900Solar24
120 Watts
330N
240 Volts AC
3 Amps
250 mm/sec
900 kg
-20°c - +50°c
and the
