Pushing Aid; Boost Function; Lighting - FiT REMOTE DISPLAY Instruction Manual

INSTRUCTION MANUAL

6.1.4 PUSHING AID

Assistance mode icon:
The pushing aid makes it easier to push the e-bike. The e-bike can be moved out of underground parking or along
steep paths comfortably by activating the pushing aid.
Briefly press the pushing aid / boost button to activate pushing aid mode. Press again to start the pushing aid.
If you release the pushing aid / boost button for more than five seconds, you will leave pushing aid mode. Pushing
aid speed can be adjusted via the settings menu.
While using the pushing aid, the pushing aid speed can be temporarily reduced / increased via the buttons on the TE1
trigger.
Exclamat
CAUTION
When using the pushing aid, the wheels must be in contact with the ground, otherwise there is a risk
of injury.
6.1.5

BOOST FUNCTION

Assistance mode icon:
The Boost function can be used to briefly increase motor support to FLY level regardless of the selected assistance
level (ECO, FLOW, FLEX). This function can be activated at speeds of 7 km/h and over and if at least one quarter pedal
revolution has been detected. The Boost function cannot be used if the pushing aid mode is active.
Press the Pushing aid / Boost button to activate the Boost function. The Boost function is activated as long as the
button is held down.

6.2 LIGHTING

You can use the light button to switch between the following lighting modes (availability depends on the model):
Symbol Description
Dimmed headlight
Main beam
Light off
Different lighting systems are fitted depending on the bike type and field of use. If the system features a daytime
running light function, the bike switches between the dimmed and daytime running lights automatically.
The dimmed headlight is permanently activated on S pedelecs because of EU directives. Pressing the light button will
activate or deactivate the main beam as well.
FIT_Manual_Remote_Display_Pinion_V3_en | Version 03 | 24.10.2023
FIT REMOTE DISPLAY PINION
14
