- Page 1 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 500085 | 500092 | 501262 | 500429 Biketec GmbH Luzernstrasse 84 NETWORKED CH-4950 Huttwil CUSTOMISED T +41 62 959 53 00 INTELLIGENT info@biketec.ch fit-ebike.com...
-
Page 2: Table Of Contents
FIT DISPLAY COMPACT ........ - Page 3 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 9 ERROR MESSAGES 9.1 GENERAL INFORMATION ..........37 9.2 STATUS LED ON OPERATING ELEMENT AND DISPLAY .
-
Page 4: Preface
1 PREFACE Dear FIT customer, The FIT system offers many useful functions and options and we are pleased that you have decided to choose our system. Please read through the operating instructions carefully to ensure you use the system safely and get off to a quick start. -
Page 5: About These Operating Instructions
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 2 ABOUT THESE OPERATING INSTRUCTIONS 2.1 MANUFACTURER Biketec GmbH Luzernstrasse 84 CH-4950 Huttwil fit-ebike.com/en-en/ 2.2 LANGUAGE The original operating instructions are written in German. A translation is invalid without the original operating in- structions. -
Page 6: Safety Instructions
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 3 SAFETY INSTRUCTIONS 3.1 GENERAL INFORMATION Please read all safety instructions carefully. Failure to comply with the warnings or take residual risks into account may result in electric shock, fire and / or serious injury. -
Page 7: Product And Technical Specifications
FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 4 PRODUCT AND TECHNICAL SPECIFICATIONS 4.1 FIT DISPLAY COMPACT The FIT Display Compact combines the same functions in a compact 2” display as in its larger counterpart, offering optimum visibility in a small design. 4.1.1 DISPLAY AND SETTINGS The following display elements remain the same on all screens and show the key settings and information about the vehicle and the current trip. -
Page 8: Operating Element
4.2.1 FIT REMOTE BASIC The ergonomic operating element FIT Remote Basic allows you to control the FIT Display easily and safely, even while riding. The button backlit by LEDs and the vibration feedback ensure optimum usability, even in the dark or while wearing gloves. -
Page 9: Fit Remote Eshift
4.2.2 FIT REMOTE ESHIFT The ergonomic FIT Remote eShift control unit allows the FIT display to be controlled easily and safely, even while riding. The LED-backlit buttons and vibration feedback guarantee ease of operation even when wearing gloves or in the dark. -
Page 10: Pinion Te1 E-Trigger
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 4.2.3 PINION TE1 E-TRIGGER The compact Pinion TE1 e-trigger gear lever has been specially developed for shifting with Pinion Smart.Shift shift technology. The goal was to provide clear haptic feedback. With a defined lever path and sophisticated micro button tuning, you can precisely initiate each shifting process. -
Page 11: Proper Use
FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 4.3 PROPER USE The operating element and the display are designed to control a FIT e-bike system and display trip data. 4.4 IMPROPER USE Improper use refers to use which is not described under proper use or goes beyond proper use. -
Page 12: Transportation And Storage
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 5 TRANSPORTATION AND STORAGE 5.1 TRANSPORTATION Exclamat CAUTION Remove battery before transportation. There is a risk of injury if the drive system is switched on unintentionally. 5.1.1 TRANSPORTING E-BIKES Protect the electrical components and connections on the e-bike from the elements with suitable protective covers. -
Page 13: Fitting
6.1 FITTING THE FIT DISPLAY COMPACT As the mount docks available to hold the display are identical, the FIT Universal Mount is used as an example to show how the display is fitted into place. The display is fitted in the same way on the FIT Display Center Mount. - Page 14 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Removing FIT Display Compact 1. Remove the anti-theft securing screw if you have one fitted. 2. Press the unlocking mechanism. 3. Remove display, pulling it upwards. FIT_Manual_Display_Compact_Remote_Basic_EShift_Pinion_V3_en | Version 03 | 24.10.2023...
-
Page 15: Operation
7.1.2 PAIRING / COUPLING THE FIT KEY CARD WITH THE FIT E-BIKE CONTROL APP The FIT Key Card is your ticket to the digital FIT world for every e-bike with FIT 2.0 integration. The individual ID is based on the SmartX technology from ABUS and ensures a secure connection to the e-bike with a unique key. -
Page 16: Assistance Modes
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Follow the instructions in the FIT E-Bike Control app 7.1.3 ASSISTANCE MODES You can set the assistance levels using the + and – buttons on the control unit. -
Page 17: Pushing Aid
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 7.1.4 PUSHING AID Assistance mode icon: The pushing aid makes it easier to push the e-bike. The e-bike can be moved out of underground parking or along steep paths comfortably by activating the pushing aid. -
Page 18: Eshift
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 7.3 ESHIFT You can select the gear shift manually with the up / down button. Symbol Description Current selected speed Gear recommendation – change up a gear Gear recommendation – change down a gear 7.4 WARNING / ERROR SYMBOLS... -
Page 19: Main / Sub-Screens
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 7.5 MAIN / SUB-SCREENS MAIN DRIVE SCREEN 1. Current speed 2. The hatched part indicates that the battery is in Long Life mode. If Long Life mode is deactivated, the hatching disappears. - Page 20 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION TRIP SUB-SCREEN 1. Difference in altitude ridden during the current trip 2. Average battery consumption during the current trip TRIP SUB-SCREEN 2 1. Maximum speed for the current trip 2.
- Page 21 1. Current temperature AREA SUB-DISPLAY The weather forecast is only available in conjunction with the FIT E-Bike Control app. To use the FIT E-Bike Control app, the smartphone must be connected to the e-bike using the FIT Key Card (see Section 7.1.2).
-
Page 22: Navigation
FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 7.5.1 NAVIGATION Navigation is only available in conjunction with the FIT E-Bike Control app. To use the FIT E-Bike Control app, the smartphone must be connected to the e-bike using the FIT Key Card (see section 7.1.2). - Page 23 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION After entering the start and end point, information about the selected route is dis- played: 1. Distance to the target. 2. The red battery symbol indicates that the current charging status is not sufficient to reach the destination in any assistance level.
- Page 24 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION The PLANNED TOURS menu displays the planned tours of the linked komoot account with information on duration, route length, highest and lowest points. Here you can select a tour for navigation.
- Page 25 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION NAVI MAIN DISPLAY If navigation on the smartphone has not been started, the following message appears. If navigation has been started on the smartphone, the following display appears.
- Page 26 FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION DISPLAY CALLS The call display is only available in conjunction with the FIT E-Bike Control app. To use the FIT E-Bike Control app, the smartphone must be connected to the e-bike using the FIT Key Card (see section 7.1.2).
-
Page 27: Charge Indicator
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 7.6 CHARGE INDICATOR Menu – Charge The charge indicator appears as soon as the charger is connected to the e-bike. Use the plus / minus button to select the charging mode (NORM, FAST, STORE) and save it by pressing the rocker switch. The Long Life mode can be switched on or off with the light button. - Page 28 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION LONG LIFE MODE CHARGING 1. Current charging mode 2. Long Life mode (green background = switched on) 3. Current battery charge level 4. As the battery is not fully charged in Long Life mode, the rest is gray-hatched 5.
-
Page 29: Settings Menu
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 8 SETTINGS MENU The settings menu is the last screen, which can be accessed by pressing the rocker switch to the right. It can only be accessed when the e-bike is stationary. -
Page 30: Menu Structure
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 8.2 MENU STRUCTURE 1. Reset values (a) Reset trip i. Reset manually ii. Reset automatically (b) Factory settings 2. Basic settings (a) Language (b) Date and time i. Time ii. -
Page 31: Setting Options
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 8.3 SETTING OPTIONS Menu – Reset values The tour data and the system can be reset to the factory settings in this menu. Reset trip Resets the trip data. You can choose between resetting manually (one-time) or resetting automatically according to... - Page 32 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Date You can set the current date in the date menu. The current digit can be changed by pressing the plus / minus button. Select the number to be changed with the selection rocker switch. Press the selection rocker switch to save the date and quit the menu.
- Page 33 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Vibration feedback The vibration can be set as feedback from the control unit in the vibration feedback menu. The following setting options are available: Selection Description No vibration feedback...
-
Page 34: Eshift Settings
8.4 ESHIFT SETTINGS 8.4.1 PINION MGU / ESHIFT Gear assignment – Select the gear direction for the up- / down button on the FIT remote EShift or Pinion TE1 gear lever or similar. Smart.Shift – Your MGU has Pinion Smart.Shift technology. This shifts the internal gear- box electrically in fractions of a second. - Page 35 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION As you roll, Pre.Select automatically switches to the gear that matches your speed. So, for example, you are always in the right gear on flowing trail sections, even without pedaling or manual shifting.
- Page 36 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION An error occurred during calibration. FIT_Manual_Display_Compact_Remote_Basic_EShift_Pinion_V3_en | Version 03 | 24.10.2023...
-
Page 37: Error Messages
The operating element and the display each feature a status LED to indicate error statuses. The operating element’s LED is located in the rocker switch. It is in the top left-hand corner in Display Compact and in the top right-hand corner in Display Comfort. - Page 38 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION INFORMATION 1. Error message 2. Error code 3. Current speed WARNING 1. Error message 2. Error code 3. Current speed ERROR / CRITICAL ERROR 1. Error message 2. Error code...
-
Page 39: Error Table
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 9.3.1 ERROR TABLE If the last two digits are listed with ”xx” as a placeholder, this provides the specialist dealer with additional information for error analysis. 0A-xx up to 28-xx... - Page 40 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 0C-02 Remote display identification error 1. Restart the system. 2. Switch the system off. 3. Remove display from holder, check contacts and clean if necessary.
- Page 41 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 0D-07 Speed node authentication error 1. Restart the system. 2. If the problem persists, please contact your specialist dealer. 0D-08 Gears authentication error 1.
- Page 42 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 0F-0A Charger update error 1. Restart the system. 2. Switch the system off. 3. Disconnect the charger from the system and socket.
- Page 43 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 12-0A Remote charger pairing error 1. Restart the system. 2. Switch the system off. 3. Disconnect the charger from the system and socket.
- Page 44 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 15-0A Remote charger pairing error 1. Restart the system. 2. Switch the system off. 3. Disconnect the charger from the system and socket.
- Page 45 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 16-0B Lock theft detection 1. Restart the system. 2. If the problem persists, please contact your specialist dealer. 17-00 Remote defective component 1.
- Page 46 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 18-02 Display start error 1. Restart the system. 2. Switch the system off. 3. Remove display from holder, check contacts and clean if necessary.
- Page 47 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 1C-xx Bluetooth module error 1. Restart the system. 2. Restart FIT E-Bike Control (app), update if necessary. 3. If the problem persists, please contact your specialist dealer.
- Page 48 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 29-xx up to 47-xx Error code Error message displayed Action / Restriction 29-xx Display communication error 1. Restart the system. 2. If the problem persists, please contact your specialist dealer.
- Page 49 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 49-09, 49-0A Motor error 1. Check if one or both trigger buttons are pressed constantly, if so: Release buttons. 2. Restart the system.
- Page 50 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 4D-08 Gear error 1. Stop the bike, release the pedals, wait 3 seconds. Stop, release pedals 2. Restart the system with no pressure on the pedals.
- Page 51 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 68-01, 68-05, Battery current error 1. Switch the system off. 68-06, 68-07, Discharging error 2. Remove the battery. 68-09, 68-16, 3.
- Page 52 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction 69-04, 69-0D Battery temperature error 1. System operating below the permissible temperature. 2. Allow the battery to warm up in a warm environment (>...
- Page 53 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Error code Error message displayed Action / Restriction FF-xx Battery start error 1. Restart the system. 2. If the problem persists, please contact your specialist dealer. 86-xx up to 8A-xx...
- Page 54 INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 8B-xx up to 92-xx Error code Error message displayed Action / Restriction 8B-xx Gears authentication error 1. Restart the system. 2. If the problem persists, please contact your specialist dealer.
-
Page 55: Cleaning And Servicing
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 10 CLEANING AND SERVICING 10.1 BASIC CLEANING 10.1.1 CLEANING THE DISPLAY AND OPERATING ELEMENT INFO-CIR NOTICE The display and operating element will be permanently damaged if water enters them. -
Page 56: Troubleshooting, Fault Clearance And Repair
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 11 TROUBLESHOOTING, FAULT CLEARANCE AND REPAIR 11.1 TROUBLESHOOTING AND FAULT CLEARANCE 11.1.1 DRIVE SYSTEM OR DISPLAY DOES NOT START UP If the display and / or the drive system do not start up, proceed as follows: 1. -
Page 57: Repair
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION Symptom Cause Remedy The assisted The battery does not perform as This does not indicate a problem. journey distance well in winter weather. is too short. The journey distance can be 1. -
Page 58: Recycling And Disposal
INSTRUCTION MANUAL FIT DISPLAY COMPACT + FIT REMOTE BASIC / ESHIFT PINION 12 RECYCLING AND DISPOSAL 12.1 DISPOSAL Mechanical and electrical equipment, accessories and packaging should be recycled in an environmentally sound manner. Don’t throw them in the garbage! Only for EU countries: According to European Directives 2012/19/EU, 2006/66/EC and their transposition into national law, defective or unusable waste electrical and electronic equipment, rechargeable batteries and batteries must be collected separately and recycled in an environmentally sound manner.
