INSTRUCTION MANUAL
4.3 PROPER USE
The operating element and the display are designed to control a FIT e-bike system and display trip data.
4.4 IMPROPER USE
Improper use refers to use which is not described under proper use or goes beyond proper use.
4.5 TECHNICAL DATA
4.5.1 FIT REMOTE DISPLAY
Display
Product code
Operating temperature
Storage temperature
Protection class
Weight about
FIT_Manual_Remote_Display_Pinion_V3_en | Version 03 | 24.10.2023
FIT REMOTE DISPLAY
500093 (cable length 450mm, without spacer)
501103 (cable length 800mm, without spacer)
501263 (cable length 450mm, with spacer)
501264 (cable length 800mm, with spacer)
°C
-5 Up to +40
°C
-10 Up to +50
IPX7
kg
0,1
FIT REMOTE DISPLAY PINION
10
