Machine In Operation With Water Tank - Profitec DRIVE User Manual

Figure 1 (Rear view)
Rotary valve in
fixed water position
(facing to the outside of
the machine)
Important!
• If you haven't programmed automatic on/off times for your machine (see chapters
8.2 - 8.6), make sure to close the shut-off valve at the end of the machine's
i
operation, switch off the machine and unplug it after each use.
• If you are not going to use the machine for a long time, we recommend emptying
the machine. To do this, let the machine heat up, then switch it off and remove the
water via the brew group and the hot water wand. Make sure that the water supply is
disconnected.
To refill, follow the initial set up(see chapter 5).
The residual water is disposed off periodically by emptying out the water drip tray.

4.3.3 Machine in operation with water tank

i
The machine is delivered in the water tank mode by default.
When operating the machine with the water tank, turn the control valve in the direction of the water
connection nozzle (see figure 3). Additionally, in the menu, set the "Tank Mode" option to "ON"
(see figure 4).
Figure 3 (Rear view)
Rotary valve in
fixed water position
(facing to the inside of
the machine)
Important!
If you haven't programmed automatic on/off times for your machine (see chapters
•
8.2 - 8.6), make sure to close the shut-off valve at the end of the machine's
i
operation, switch off the machine and unplug it after each use.
• If you are not going to use the machine for a long time, we recommend emptying
the machine. To do this, let the machine heat up, then switch it off and remove the
water via the brew group and the hot water wand. Make sure that the water supply is
disconnected.
To refill, follow the initial set up(see chapter 5).
The residual water is disposed off periodically by emptying out the water drip tray.
Translation of the original German user manual
Water connection nozzle
Water connection nozzle
Figure 2
Tank mode option "OFF"
Figure 3
Tank mode option "OFF"
ENGLISH
40
