MC50SC
USER/INSTALLER MANUAL
24V
v7.2
REV. 03/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC50SC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Motorline professional MC50SC

  • Page 1 MC50SC USER/INSTALLER MANUAL v7.2 REV. 03/2021...
  • Page 2: Table Of Contents

    00. CONTENT INDEX 01. SAFETY INSTRUCTIONS 07. COMPONENTS TEST CAPACITOR SCHEME STANDARDS TO FOLLOW INPUTS TEST 02. THE CONTROL BOARD 08. TROUBLESHOOTING TECHNICAL SPECIFICATIONS INSTRUCTIONS FOR FINAL CONSUMERS/ TECHNICIANS PROGRAMMING PRE-RECOMENDATIONS 09. CONNECTION SCHEME 03. INSTALLATION CONNECTIONS MAP ESSENTIAL STEPS FOR INSTALLATION TRANSMITTERS "P"...
  • Page 3: Safety Instructions

    STANDARDS TO FOLLOW TECHNICAL SPECIFICATIONS ATTENTION: The MC50SC is a monophasic control board com a control system via incorporated rádio, developed for the automation of sliding gates. This product is certified in accordance with European Community (EC) safety standards. • Power supply 230V AC 50-60Hz •...
  • Page 4 02. THE CONTROL BOARD 02. THE CONTROL BOARD TECHNICAL SPECIFICATIONS PROGRAMMING PRE-RECOMENDATIONS 01 • Safety Edge LS • LED lit when the pedestrian push button is active 02 • Photocells LO • LED lit when the total push button is active 03 •...
  • Page 5: Installation Essential Steps For Installation

    03. INSTALLATION 03. INSTALLATION ESSENTIAL STEPS FOR INSTALLATION TRANSMITTERS The installation process assumes that the gate has already limit switches Transmitter programming for total opening. plates installed. For more information consult the motor's manual. Transmitter programming for pedestrian opening. • PROGRAMMING TRANSMITTERS •...
  • Page 6: P" Menu Functions 5A

    03. INSTALLATION 03. INSTALLATION "P" MENU FUNCTIONS "E" MENU FUNCTIONS • We can only go into programming with a electrically closed gate. • We can only go into programming with a electrically closed gate. • To access the P menu •...
  • Page 7: Programming "P

    04. PROGRAMMING "P" 04. PROGRAMAR "P" AUTOMATIC PROGR. OF THE COURSE SEMI-AUTOMATIC PROGR. OF THE COURSE This menu allows automatic programming of the motor and deceleration. This submenu performs a semi-automatic programming of the working time of the motor, set- ting the slow speed areas manually.
  • Page 8: P1-Setting The Deceleration Time 7A

    04. PROGRAMMING "P" 04. PROGRAMMING "P" SETTING THE DECELERATION TIME SETTING THE DECELERATION TIME Opening deceleration Closing deceleration Deceleration type It allows to define the slowdown time in the It allows defining the slowdown time in the It allows to set the slowdown speed, according to the automation power. opening phase.
  • Page 9: P2-Setting Strength And Sensitivity

    04. PROGRAMMING "P" SETTING STRENGTH AND SENSITIVITY If you set the sensitivity (FS) to a value greater than 1, the force (FO) is automatically set to without the possibility to change it. Note: If the control board has very high sensitivity values, you may see the LI error. After four attempts, the LI error will turn ER.
  • Page 10: P3-Pedestrian Course Time 9A

    04. PROGRAMMING "P" 04. PROGRAMMING "P" PEDESTRIAN TIME PAUSE TIME The pedestrian mode allows the gate to open for the passage of people without the need to fully open. Pause time adjustment of Pause time adjustment of This function can set the time you want the gate to open. the total closure the pedestrian closure Allows you to set the...
  • Page 11: P5-Photocells Programming 10A

    04. PROGRAMMING "P" 04. PROGRAMMING "P" PHOTOCELLS PROGRAMMING SAFETY BAND 00 (disables photocells) 00 (photocells during the closing) 00 (disables safety band) 00 (8k2 input) 00 (band during closure) 01 (ables photocells) 01 (photocells during the opening) 01 (ables safety band) 01 (NC input) 01 (band during opening) With the photocells activated,...
  • Page 12: P7-Operating Logic 11A

    04. PROGRAMMING "P" 04. PROGRAMMING "P" OPERATING LOGIC FLASHING LIGHT This menu allows you to set the gate's operating mode. Intermittent During movement of Courtesy light (opening and closing) the gate (opening and During operation it Functioning in automatic Functioning in step by Functioning in During the gate's closing), the flashing...
  • Page 13: P9-Distance Programming 12A

    04. PROGRAMMING "P" 05. PROGRAMMING "E" DISTANCE PROGRAMMING PRESENT MAN Present man - closing Push button mode 02 (activates present man at the closing) distance PGM OFF distance PGM ON The present man is active only in LS Button LO Button closing.
  • Page 14: E1-Soft Start

    05. PROGRAMMING "E" 05. PROGRAMMING "E" SOFT START COURTESY LIGHT TIME 00 disabled function This menu allows you to define the time (from 1 to 99 minutes) that 01 enabled function the courtesy light stays on after the gate has completed an opening or This menu allows you to enable/disable soft start.
  • Page 15: E5-Electric Brake 14B

    05. PROGRAMMING "E" 05. PROGRAMMING "E" FOLLOW ME ELECTRIC BRAKE E4 MENU INACTIVE. 00 disabled function 01 enabled function This menu allows you to activate the option Follow me. With this function activated whenever the photocells detect the passage of a user/obstacle, the control board triggers the closing operation after 3 seconds.
  • Page 16: E6-Deceleration Speed 15A

    05. PROGRAMMING "E" DECELERATION SPEED MANEUVER COUNTER This menu allows you to check how many complete maneuvers were performed by the control board (complete maneuver it is understood by opening and closing). The control board reset does not erase the maneuvers count. Example: 13456 maneuvers 01- Hundreds of thousands / 34- Thousands / 56- Dozens This menu lets you set the deceleration speed in opening and closing.
  • Page 17: E8-Reset - Restore Factory Values

    05. PROGRAMMING "E" 05. PROGRAMMING "E" RGB OUTPUT RESET - RESTORE FACTORY VALUES By doing reset, all factory settings will be restored and all saved commands will be deleted. Only the maneuvers counter will have the data memorised. Continuous light Flashing light (factory default 01) This menu allows you to select the functioning mode of the four signs, fixed or intermittent...
  • Page 18: Display

    06. DISPLAY DISPLAY INDICATIONS MENU DESCRIPTION MENU DESCRIPTION Opening limit-switch enabled Obstructed photocells No limit switches or both open Closing limit-switch enabled limit switches In pause time Security Band under pressure Pedestrian button being In pedestrian pause time pressed Memory full Start button being pressed Memory full (pedestrian) Sensibility detection failure...
  • Page 19: Components Test

    07. COMPONENTS TEST 07. COMPONENTS TEST CAPACITOR SCHEME INPUTS TEST To detect which components have problems during a sliding automatism installation, In the position corresponding to each transmitter input in low voltage, the control board has a LED to identify the condition of it. The LED on indicates that the input is closed, while the sometimes it's necessary to conduct tests with a direct connection to a 230V power LED off indicates that the input is open.
  • Page 20: Troubleshooting

    08. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem • Motor • Make sure you have • Still not working. • Consult a qualified 1 • Open control box and check if 3 •...
  • Page 21: Connection Scheme

    09. CONNECTION SCHEME CONNECTIONS MAP Photocell Antenna RGB Flashing Safety Band light CLOSE Limit-switch Photocell OPEN key selector/pushbutton key selector/pushbutton (Total) (Pedestrian) Flashing light Permanent Motor Condenser...
