- Page 1 USER’S AND INSTALLER’S MANUAL V6.4 REV. 04/2024...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX This product is certified in accordance with European Community 01. SAFETY INSTRUCTIONS (EC) safety standards. STANDARDS TO FOLLOW This product complies with Directive 2011/65/EU of the European 02. PACKAGE Parliament and of the Council, of 8 June 2011, on the restriction INSIDE PACKAGE of the use of certain hazardous substances in electrical and electronic equipment and with Delegated Directive (EU) 2015/863... -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can... - Page 4 01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse.
-
Page 5: Package
03. MOTOR INSIDE PACKAGE TECHNICAL SPECIFICATIONS In the package you will find the following components: Specifications are as follow: 01 • 02 Swing motors JAG400 JAG600 02 • 01 Control Board 03 • 02 remote controls (4 channels) 230V 230Vac 50/60Hz 230Vac 50/60Hz 04 •... -
Page 6: Unlock Motor
03. MOTOR 04. INSTALLATION TECHNICAL SPECIFICATIONS HEIGHT OF THE SUPPORTS JAG 400 || 600 dimensions are the following: Motor must be installed with a small inclination , to prevent water infiltration through the extension arm. For this, the front support must be fixed to the gate with a height lower than the height of the rear support. -
Page 7: Interior Opening Installation Dimensions
04. INSTALLATION INTERIOR OPENING INSTALLATION DIMENSIONS On the Illustrated diagrams below and on the next page, are the dimensions for the installation of the automation. * The installation of opening stopper is not mandatory. (EXTERIOR) Axis of rotation of the motor, on the front support Legend: Dimension X - Horizontal distance between hinge axis of the gate and the axis axle of the motor. -
Page 8: External Opening Installation Dimensions
04. INSTALLATION EXTERNAL OPENING INSTALLATION DIMENSIONS On the Illustrated diagrams below and on the next page, are the dimensions for the installation of the automation. * The installation of opening stopper is not mandatory. Legend: Dimension X - Horizontal distance between hinge axis of the gate and the rear axis of rotation of the motor. *Stopper at the Dimension Y - Vertical distance between hinge axis of the gate and the rear axis of rotation of the motor. -
Page 9: Installation Steps 8A
04. INSTALLATION 04. INSTALLATION INSTALLATION STEPS INSTALLATION STEPS Pay attention to the installation dimensions mentioned on pages 4B, 5 and 6! 03 • Test the movement. • Place the dowels in each support with a small amount of lubricant so that there is no excessive friction. - Page 10 04. INSTALLATION 04. INSTALLATION MICROS ADJUSTMENT MICROS ADJUSTMENT 01 • Unlock the motor (see page 4A). 06 • Take the gate to the open position. 02 • Loosen the 3 front screws, remove the cover and the profile cover. 07 • Loosen the screw shown in the image (24), so that it is possible to move the micro-switch in the profile.
-
Page 11: Installation Map
04. INSTALLATION INSTALLATION MAP CONTROL FLASHING MOTOR BOARD LAMP ANTENNA SELECTOR EXTERIOR PHOTOCELLS JUNCTION BOX EXTERIOR INTERIOR PHOTOCELLS PHOTOCELLS GATE STOPPER LEGEND: Connection cables It is important to use stoppers at the opening and closing of the gate. If not respected, It is important to use junction boxes for connections between motors, components and components of the automation may suffer efforts for which they were not prepared, and control board. -
Page 12: Connection Scheme
06. COMPONENTS TEST 05. CONNECTION SCHEME 110V/230V MOTOR 24V MOTOR To detect which are the components with problems in a 24V JAG automatism installation, it is necessary to conduct tests with a direct connection to a external power supply (battery 24V). The diagram below shows how to make this connection. -
Page 13: 230V/110V Motor
06. COMPONENTS TEST 230V/110V MOTOR To detect if the malfunction is on the control board or on the motor All tests must be performed by specialized NOTES: is, sometimes, necessary to perform tests with direct connection to technicians due to serious danger associated •... -
Page 14: Maintenance
07. MAINTENANCE MAINTENANCE • Clean the tube • With a cloth soaked in lubricant spray, clean all the residues that accumulate in the automation tube. • Apply a small amount of lubricant spray on the tube and using a dry cloth remove the excess, leaving an even layer on the tube. -
Page 15: Troubleshooting
08. TROUBLESHOOTING FINAL CONSUMERS INSTRUCTIONS INSTRUCTIONS FOR SPECIALIZED INSTALLERS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem 1 • Open control board and check control board and test them by problem is on the control board. remove them from installation •...
