  • Page 1 Manufacturer: Dymax® Product Name: Dymax BlueWave® MX-150 LED Emitter - 405nm Manufacturer Part Number: 42338 Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm BlueWave MX-150 ® LED Spot-Curing Emitters User Guide Contact the professionals at Fiber Optic Center for a quote or to get more details.
  • Page 2 Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Introduction This guide describes how to set up, use, and maintain BlueWave ® MX-150 emitters safely and efficiently. Intended Audience This user guide is meant for experienced process engineers, technicians, and manufacturing personnel.

  • Page 3: Product Overview

    Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Product Overview Description of BlueWave MX-150 Emitters • When paired with a MX-series controller, BlueWave MX-150 emitters function as a high-intensity spot-curing system. The system can be set up in many configurations and can be used with a lightguide if needed.

  • Page 4: Installation

    Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Unpacking Upon arrival, inspect all boxes for damage and notify the shipper of box damage immediately. Open each box and check for equipment damage. If parts are damaged, notify the shipper and submit a claim for the damaged parts.
  • Page 5 Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm • If emitter aperture glass is permanently contaminated it must be replaced for safe operation. Mounting/Connections • Each emitter has two sets of M3 x 0.5 mm holes (Figure 1) that align with Dymax stands and holders.

  • Page 6: Troubleshooting And Maintenance

    Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Troubleshooting & Maintenance Problem Possible Cause Corrective Action LED intensity adjustment Increase LED intensity setting. set to 0% or too low LED cycle time is set to 0...

  • Page 7: Spare Parts

    Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Product Cleaning and Care • Product cleaning is limited to wiping the product with a damp cloth. Do not soak. Isopropanol Alcohol or household cleaners may be used for cleaning the product.

  • Page 8: Compatible Devices

    Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Compatible Devices Item Part Number Controllers BlueWave ® MX Series 2-Channel Controller/Power Supply - US 43185 BlueWave ® MX Series 4-Channel Controller/Power Supply - US 43182...

  • Page 9: Specifications

    Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Specifications Property Specification Emitter RediCure PrimeCure VisiCure Output Frequency 365 nm 385 nm 405 nm Typical Intensity Output* 24 W/cm 38 W/cm 36 W/cm Emitter Dimensions 1.97"...

  • Page 10: Declaration Of Conformity

    Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Declaration of Conformity Figure 4. Declaration of Conformity - CE Contact the professionals at Fiber Optic Center for a quote or to get more details. U S E R G U I D E B L U E W A V E M X - 1 5 0 E M I T T E R S focenter.com...
  • Page 11 Click here for more details on the Dymax BlueWave® MX-150 LED Emitter - 405nm Figure 5. Declaration of Conformity - UKCA Contact the professionals at Fiber Optic Center for a quote or to get more details. focenter.com • 508-992-6464 | (800) 473-4237 •...
