A S S E M B L Y G U I D E K I T 5 3 : T H E L E F T H A N D ( I I ) In this kit you will continue to build the left hand. 53-1 53-2 53-3...
Page 4
K I T 5 3 : T H E L E F T H A N D ( I I ) 53-7 53-7 53-7 53-7 53-7 53-7 53-1 Glue six magnets 53-7 into the circular recesses inside the Left Radius Skin 53-1. It doesn’t matter which way round the magnets are fitted.
Page 5
K I T 5 3 : T H E L E F T H A N D ( I I ) 53-4 (L5) After checking the fit of Left Finger L5 53-4 on the back of the Left Hand 53-2, glue in place.
Page 6
K I T 5 3 : T H E L E F T H A N D ( I I ) 53-8 52-1 Take the Left Hand which was 52-1 assembled in pack 7 - kit 52. Fit the free side of the Connector 52-5 over the raised screw socket on the back of Hand...
Page 7
A S S E M B L Y G U I D E KIT 54: THE LEFT HAND (III) In this kit you will continue to work on the left hand and left radius. 54-2 54-1 54-3 54-4 54-5 54-6 54-7 54-8 54-9...
Page 8
K I T 5 4 : T H E L E F T H A N D ( I I I ) 54-6 (A2) 54-5 (A1) Take the left radius skin 53-1 from the previous kit. After test-fitting, glue Pipes A2 54-6 and A1 54-5...
Page 9
K I T 5 4 : T H E L E F T H A N D ( I I I ) 54-3 Insert the Pin 54-7 into the central hole in the Wrist Joint 54-3. 54-7 54-9 54-9 Take the left hand assembly from the previous kit and fit the Wrist Joint 54-3...
Page 10
K I T 5 4 : T H E L E F T H A N D ( I I I ) 54-2 53-8 53-8 53-6 52-1 52-1 53-2 53-2 The connector 53-6, supplied with Test-fit the pegs on the underside the previous kit, is fitted across parts of the Left-hand Palm 54-2...
Page 11
A S S E M B L Y G U I D E K I T 5 5 : T H E L E F T R A D I U S In this kit you will continue to build the left radius and its appendages. 55-2 55-3 55-1...
Page 12
K I T 5 5 : T H E L E F T R A D I U S 55-7 55-7 Lay the Left Radius Skin 55-1 on the work surface and glue six Magnets 55-7 into the circular recesses, as shown. It doesn’t matter which way round 55-1 the magnets are fitted.
Page 13
K I T 5 5 : T H E L E F T R A D I U S 55-8 55-4 (A3) 55-2 55-5 53-1 55-3 Repeat the previous step to fit Pipe A3 55-4 into Join the two parts of the Radius the remaining slots in the Protector 55-2...
Page 14
A S S E M B L Y G U I D E K I T 5 6 : T H E R A D I U S A N D T H E H U M E R U S In this kit you will complete the build of the left radius and start assembling parts of the humerus.
Page 15
K I T 5 6 : T H E R A D I U S A N D T H E H U M E R U S Take the skin 55-1 from 56-1 the previous kit and place the Left Radius 56-1 inside it.
Page 16
K I T 5 6 : T H E R A D I U S A N D T H E H U M E R U S 56-7 56-7 56-7 56-1 Secure the radius assembly 54-1/56- together with six 2.3x6mm screws 56-7.
Page 17
K I T 5 6 : T H E R A D I U S A N D T H E H U M E R U S 56-4 (A6) 56-6 56-6 56-6 56-6 56-5 (A7) 56-2 56-2 Repeat the previous step to glue Pipes A6 56-4 and A7...
Page 18
A S S E M B L Y G U I D E K I T 5 7 : T H E L E F T H U M E R U S In this kit you will build the outer skin covering of the left humerus and its appendages. 57-2 57-1 57-3...
Page 19
K I T 5 7 : T H E L E F T H U M E R U S 57-2 (A8) 57-1 Take the Left Humerus Skin 57-1 and test-fit the tabs on Pipe A8 57-2 into the slots along the side.
Page 20
K I T 5 7 : T H E L E F T H U M E R U S 57-5 57-5 57-5 Turn the Left Humerus Skin 57-1 over and glue eight Magnets 57-5 into the circular recesses inside. It doesn’t matter 57-1 which way up the magnets are fitted.
Page 21
K I T 5 7 : T H E L E F T H U M E R U S 57-5 Take the humerus skin 56-2 from the previous kit. Glue four Magnets 57-5 57-5 into the circular recesses on the inside of the skin. It doesn’t matter which way up they are fitted.
Page 22
A S S E M B L Y G U I D E K I T 5 8 : T H E L E F T H U M E R U S ( I I ) In this kit you will continue working on parts of the Xenomorph’s left humerus. 58-1 58-2 58-3...
Page 23
K I T 5 8 : T H E L E F T H U M E R U S ( I I ) 58-1 EXPERT TIP: As many of the parts are similar and need to be kept to one side at times, it may help to label each part on the underside.
Page 24
K I T 5 8 : T H E L E F T H U M E R U S ( I I ) 58-5 56-2 58-2 With the humerous skin 56-2 still on the work surface, place the Left Humerous 58-2 inside it sideways,...
Page 25
K I T 5 8 : T H E L E F T H U M E R U S ( I I ) 58-2 Separate the parts and put the skin 56-2 aside. 56-2 58-5 Take the skin 57-1 from the previous kit and in a similar way to step 3,...
Page 26
K I T 5 8 : T H E L E F T H U M E R U S ( I I ) 58-6 58-2 58-4 57-1 58-3 Join the two parts of the Remove the Humerus 58-2 from the Humerus Protector 58-3 skin...
Page 27
A S S E M B L Y G U I D E K I T 5 9 : T H E L E F T H U M E R U S ( I I I ) In this kit you will continue working on parts of the Xenomorph’s left humerus. 59-1 59-2 59-3...
Page 28
K I T 5 9 : T H E L E F T H U M E R U S ( I I I ) 59-9 Fit the holes in Humerus Protector 59-4 over the raised screw sockets on Humerus Protector 59-3.
Page 29
K I T 5 9 : T H E L E F T H U M E R U S ( I I I ) Two further Magnets 59-5 fitted into circular recesses inside the Left Humerus 59-1. Fit the Humerus 59-1 sideways into the...
Page 30
K I T 5 9 : T H E L E F T H U M E R U S ( I I I ) 59-1 59-2 56-1 59-2 Take the forearm and fit a Washer 59-2 over the raised socket at the end of parts 58-2 58-2...
Page 31
K I T 5 9 : T H E L E F T H U M E R U S ( I I I ) 59-8 59-8 58-2 Secure parts 58-2 59-1 together using four 2.3x6mm screws 59-8. 59-1 KIT 59 IS COMPLETE Another humerus protector has been assembled and more magnets added to the humerus.
Page 32
A S S E M B L Y G U I D E K I T 6 0 : T H E L E F T A R M ( I ) In this kit you will continue building the left arm and the assembly of the skin covering of the left humerus.
Page 33
K I T 6 0 : T H E L E F T A R M ( I ) Take the left arm assembly which was worked on in the previous kit. Carefully open 60-3 Elbow Skin 60-3 and fit it over the elbow as shown in the diagram;...
Page 34
K I T 6 0 : T H E L E F T A R M ( I ) Locate the six pegs on the inside of the wrist 55-6. Carefully pull the edges of the wrist 55-6 apart so that it fits around the arm assembly 53-1/55-1.
Page 35
K I T 6 0 : T H E L E F T A R M ( I ) 60-4 Take the humerus part 58-1 which was worked on in kit 58 and place the Bush 60-4 over the central shaft, as shown.
Page 36
K I T 6 0 : T H E L E F T A R M ( I ) 60-2 60-1 60-4 Note the position of Humerus Joint 60-1 when fitting the assembly 60-1/60-2 over the Bush 4. Also note that there are slight ridges on Humerus Joint 60-2 58-1...
