A L I E N
spectacular
1:2
scale
EASY
ASSEMBLY
PACK 7
KITS 45 - 52
BUILD THE
TERRIFYING
XENOMORPH
FROM ALIEN

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALIEN PACK 7 and is the answer not in the manual?

Questions and answers

Related Manuals for Hachette ALIEN PACK 7

Summary of Contents for Hachette ALIEN PACK 7

  • Page 1 A L I E N spectacular scale EASY ASSEMBLY BUILD THE TERRIFYING XENOMORPH FROM ALIEN PACK 7 KITS 45 - 52...

  • Page 2: B U I L D I N S T R U C T I O N S

    Some parts may have sharp edges, please handle them with care. Hachette Partworks Ltd, 4th Floor, Jordan House, 47 Brunswick Place, London N1 6EB The installation of electronic parts must always be carried out by an adult. When replacing batteries, www.hachettepartworks.com...
  • Page 3 A S S E M B L Y G U I D E K I T 4 5 : T H E R I G H T H A N D A N D T H E S K U L L ( I I ) In this kit you will continue to assemble parts of the right hand and install a second LED assembly in the Xenomorph’s skull.
  • Page 4 K I T 4 5 : T H E R I G H T H A N D A N D T H E S K U L L ( I I ) 45-8 45-8 Glue the six Magnets 45-8 into the circular recesses inside the Radius Outer Skin 45-1.
  • Page 5 K I T 4 5 : T H E R I G H T H A N D A N D T H E S K U L L ( I I ) 45-4 (R5) Take the Hand 45-2 check the t of Right Finger R5 45-4.
  • Page 6 K I T 4 5 : T H E R I G H T H A N D A N D T H E S K U L L ( I I ) 45-9 44-2 44-6 The two halves of the hand are now joined together.
  • Page 7 K I T 4 5 : T H E R I G H T H A N D A N D T H E S K U L L ( I I ) 45-7 44-7 Study the diagrams carefully and note the position of the LED Strip 45-7 in the centre of the...
  • Page 8 A S S E M B L Y G U I D E K I T 4 6 : T H E R I G H T H A N D A N D T H E S K U L L ( I I I ) In this kit you will continue to work on the right hand and radius, plus install a third LED within the skull assembly.
  • Page 9 K I T 4 6 : T H E R I G H T H A N D A N D T H E S K U L L ( I I I ) 46-3 Insert the Pin 46-7 into the central hole of the Wrist Joint 46-3.
  • Page 10 K I T 4 6 : T H E R I G H T H A N D A N D T H E S K U L L ( I I I ) 46-10 46-10 Orientate the Bracket 46-6, as shown and t the screw holes over the raised screw sockets on parts...
  • Page 11 K I T 4 6 : T H E R I G H T H A N D A N D T H E S K U L L ( I I I ) 46-2 Test- t the pegs on the underside of the Palm of Right- hand 46-2...
  • Page 12 K I T 4 6 : T H E R I G H T H A N D A N D T H E S K U L L ( I I I ) 3-12 3-12 46-8 3-13 3-13 46-8 9V 6LR61 9V 6LR61 Take the circuit board...
  • Page 13 K I T 4 6 : T H E R I G H T H A N D A N D T H E S K U L L ( I I I ) 46-8 3-14 Take the lower head assembly 3-14 which was last worked on in pack 3 - kit 13 and fit the skull...
  • Page 14 A S S E M B L Y G U I D E K I T 4 7 : T H E R I G H T A R M ( I ) In this kit you will assemble the component pieces of the right arm and radius. 47-1 47-2 47-3...
  • Page 15 K I T 4 7 : T H E R I G H T A R M ( I ) 47-7 47-7 47-7 Lay the Radius Skin 47-1 on the work surface and glue the six Magnets 47-7 into the circular recesses, as shown.
  • Page 16 K I T 4 7 : T H E R I G H T A R M ( I ) 47-5 (B4) Take the skin 45-1, which was worked on in the last kit, and t 47-4 (B3) Pipes B3 47-4 and B4 47-5...
  • Page 17 K I T 4 7 : T H E R I G H T A R M ( I ) 47-8 47-8 47-8 46-1 Whilst keeping the parts in place, turn the assembly over and secure together using six 2.3x6mm screws 47-8.
  • Page 18 K I T 4 7 : T H E R I G H T A R M ( I ) 47-6 Locate the six pegs on the inside of the Right Wrist 47-6. Carefully pull the edges of the Wrist 47-6 apart so that it ts around the arm assembly...
  • Page 19 K I T 4 7 : T H E R I G H T A R M ( I ) 47-9 47-2 47-3 47-2 47-3 44-1 Join the two radius protector Fit the four pegs on the parts together by tting the protector 47-2/47-3 into...
  • Page 20 A S S E M B L Y G U I D E K I T 4 8 : T H E R I G H T A R M ( I I ) In this kit you will start to build the Xenomorph’s right humerus. 48-1 48-2 48-3...
  • Page 21 K I T 4 8 : T H E R I G H T A R M ( I I ) 48-2 (B5) After noting that there is a locating pin at one end of the Pipe B5 48-2, test-fit the pipe into the slots on the Right Humerus Skin 1, as shown.
  • Page 22 K I T 4 8 : T H E R I G H T A R M ( I I ) 48-5 48-5 Turn the Right Humerus Skin 48-1 over and glue the eight Magnets 48-5 into the circular recesses, 48-5 as shown.
  • Page 23 A S S E M B L Y G U I D E KIT 49: THE RIGHT ARM (III) In this kit you will continue to work on the right humerus and its attachments. 49-1 49-2 49-3 49-4 49-5 49-6 PARTS SUPPLIED Ref.
  • Page 24 K I T 4 9 : T H E R I G H T A R M ( I I I ) 49-1 The Pipes B8 49-2 49-3 are fitted next to each other into the slots on the at the edge of Right Humerus Skin 49-1.
  • Page 25 K I T 4 9 : T H E R I G H T A R M ( I I I ) 49-6 49-4 49-1 49-1 Rotate the Skin assembly 49-1 Turn the Skin assembly 49-1 over and and repeat the previous step to t the peg on the Humerus Appendage rmly glue a further two magnets 49-4...
  • Page 26 K I T 4 9 : T H E R I G H T A R M ( I I I ) 49-6 49-6 Four Magnets 49-6 are fitted 49-6 into the circular recesses 49-6 inside the Humerus 49-5. It is important that their orientation is such that they are attracted to the magnets directly below...
  • Page 27 A S S E M B L Y G U I D E KIT 50: T H E RI GHT ARM (IV ) In this kit you will continue to work on parts of the Xenomorph’s right arm. 50-1 50-2 50-3 50-4 50-5...
  • Page 28 K I T 5 0 : T H E R I G H T A R M ( I V ) EXPERT TIP: To help with the orientation, temporarily lay 50-1 the new magnet directly onto the previously fitted magnet (on the skin) and mark the upper side with a permanent pen.
  • Page 29 K I T 5 0 : T H E R I G H T A R M ( I V ) 50-1 49-5 50-6 48-1 48-1 Above left: Take the humerus assembly 1/49-5 from the previous kit and remove the humerus 5.
  • Page 30 K I T 5 0 : T H E R I G H T A R M ( I V ) 50-2 In a similar way to steps one to four, magnets are now fitted inside Right Humerus 50-2. After studying the diagrams, place Right Humerus 50-2 inside skin 49-1.
  • Page 31 K I T 5 0 : T H E R I G H T A R M ( I V ) The diagram shows the magnets fitted inside parts 50-1 and 50-2. 50-1 50-2 Take the forearm assembly which was last worked on in kit 47.
  • Page 32 K I T 5 0 : T H E R I G H T A R M ( I V ) 50-1 50-3 46-1 50-3 Fit a Washer 50-3 over the raised socket at the end of parts 50-1 and 50-2. Bring parts 50-1 50-2 50-2...
  • Page 33 K I T 5 0 : T H E R I G H T A R M ( I V ) 50-9 50-10 50-9 50-1 50-5 50-2 50-4 Secure parts 50-1 Join the two parts of the 50-2 together using four humerus protector together 2.3x6mm screws 50-9.
  • Page 34 A S S E M B L Y G U I D E K I T 5 1 : T H E R I G H T A R M ( V ) In this kit you will continue working on the Xenomorph’s right arm. 51-2 51-3 51-1...
  • Page 35 K I T 5 1 : T H E R I G H T A R M ( V ) 51-1 51-6 51-6 51-6 51-6 49-1 51-1 Take the humerus skin 49-1 which was worked on in the previous kit. Fit the Right Humerus 51-1 Fit four Magnets...
  • Page 36 K I T 5 1 : T H E R I G H T A R M ( V ) 51-10 51-4 51-10 The Elbow Skin 51-4 is held in place using four 2.3x4mm Flange screws 51-10; take care not to over-tighten these screws. Once the screws have been tted, turn the assembly over and glue the edges of the Elbow Skin...
  • Page 37 K I T 5 1 : T H E R I G H T A R M ( V ) 51-5 Take the humerus part 49-5 which was worked on in the 49-5 previous kit and place the Bush 51-5 over the central shaft, as shown.
  • Page 38 K I T 5 1 : T H E R I G H T A R M ( V ) 51-9 51-1 51-9 51-9 50-2 51-1 50-1 49-5 Humerus parts 49-5 51-1 are sandwiched over the upper end of the Holding the parts together, humerus 50-1/50-2.
  • Page 39 K I T 5 1 : T H E R I G H T A R M ( V ) 47-3 47-2 Take the radius protector 47-2/47-3 which was removed in the previous kit and fit it into the corresponding space on 44-1 the radius 44-1.
  • Page 40 A S S E M B L Y G U I D E K I T 5 2 : T H E L E F T H A N D ( I ) In this kit you will start to build parts of the left hand. 52-1 52-2 52-3...
  • Page 41 K I T 5 2 : T H E L E F T H A N D ( I ) 52-8 To join the two halves of the humerus protector together, place the holes in Protector 52-7 over the raised screw sockets in Protector 52-6 and secure in place with...
  • Page 42 K I T 5 2 : T H E L E F T H A N D ( I ) 52-3 (L2) Work now begins on the left hand. Test- t the pegs on the back of Left Finger L2 52-3 into corresponding raised sockets on the back of the...
  • Page 43 K I T 5 2 : T H E L E F T H A N D ( I ) 52-9 Fit one side of the Connector 52-5 over the raised screw socket on the back of the Left 52-5 Hand 52-1.
