  • Page 1 U 96 Pack 14 Kits 53-56 25 20 U-BOAT BUILD THE ICONIC WORLD WAR II U-BOAT...
  • Page 2 Kit 53: Non - commissioned officers' compartment (IV) Kit 54: Non - commissioned officers' compartment (V) Kit 55: The next circuit board Kit 56: Port hull section © 2023/2024 Hachette Partworks Ltd. ALL RIGHTS RESERVED Not suitable for children under 14. Hachette Partworks Ltd WARNING: All parts belong to a kit.
  • Page 3 Kit 53: Non - commissioned officers’ compartment (IV) Work on the compartment continues with the forward bulkhead, to which various items including a bulkhead hatch, several fuse boxes and a refrigeration unit are attached. 53-2 53-3 53-1 53-4 53-5 Parts reference list Part no.
  • Page 4 Kit 53: Non - commissioned officers’ compartment (IV) STAGE 1 The forward bulkhead 53-3 53-1 53-1 53-3 Place the forward bulkhead 53-1 on your work surface. Take the This photograph shows the bulkhead hatch 53-3 installed in the bulkhead hatch 53-3, apply some glue to the inside of the part, and central opening in the bulkhead 53-1, with the hinges correctly insert it into the central opening in the bulkhead 53-1, as shown in seated in the mounts.
  • Page 5 Non - commissioned officers’ compartment (IV) Take the refrigeration unit 53-2 and apply some glue to the pegs on the back. After checking the orientation of the detail in the next step, fit the pegs into the two raised 53-1 sockets on the bulkhead 53-1, as shown by the red arrows, left.
  • Page 6 Kit 54: Non - commissioned officers’ compartment (V) Work on the fourth compartment continues with the galley: the stove is fitted with a gimbal and attached to the aft bulkhead, along with the extractor hood. Two doors are also installed. 54-2 54-3 54-1...
  • Page 7 Kit 54: Non - commissioned officers’ compartment (V) STAGE 1 The fourth compartment (continued) 54-2 54-2 54-1 54-1 Place the aft bulkhead 54-1 on your work surface, positioned as The photo shows the door 54-2 attached to the bulkhead 54-1: do shown above.
  • Page 8 Kit 54: Non - commissioned officers’ compartment (V) 54-1 53-4 54-3 54-1 Apply some glue to the two pegs on the back of before inserting The stove 54-3 is glued into the corresponding slots in the bulkhead these into the two vertical slots in bulkhead 54-1, as shown above. 54-1 below the extractor hood.
  • Page 9 Kit 55: The next circuit board In this kit, you will fit a cover to a circuit board, connect various cables and then attach the cover to the back of the command room. 55-1 55-2 55-3 55-4 55-5 Parts reference list Part no.
  • Page 10 Kit 55: The next circuit board STAGE 1 Assembly and wiring of the PCB 55-1 55-3 55-2 55-1 55-3 Lay the back cover of the circuit board 55-3 on your work surface. Once the PCB 55-1 is in position on the back cover 55-3, place the front Take the PCB 55-1 and place it onto the back cover 55-3, as indicated...
  • Page 11 Kit 55: The next circuit board 28-7/L-1 49-3 55-1 The three LED cables 28-7 marked and cable 28-6 marked Insert the connectors of the three cables 28-7 marked into sockets from the second compartment (see red arrows) are now connected 1, 2 and 3 of the PCB 55-1, as shown.
  • Page 12 Kit 56: Port hull section In this kit, the assembly of the hull progresses, with an additional port (L) section. 56-1 56-2 56-3 Parts reference Screws Part no. Name 56-1 Port (L) hull plate Dimensions 56-2 Connector 2 x 4 mm 56-3 Connector 2 x 4 mm...
  • Page 13 Kit 56: Port hull section STAGE 1 Assembly of the new hull plate Place hull plate 56-1 face down on your work surface. Have ready the two 56-2 connectors 56-2 56-3 and four screws. First take connector 56-2 and fit it 56-3 over the raised screw sockets on the hull plate, as indicated.
  • Page 14 Kit 56: Port hull section Take the hull section 56-1 and insert its bottom edge behind the top edge of the lower hull section 19-1. The plate is then swivelled upwards, as indicated by the two arrows. 19-1 56-1 Attach the hull plate 56-1 to the main hull assembly using an...
