- Page 1 Sit-to-Stand Rolling Adjustable Height Laptop Cart With Storage MODEL RTA-B002 ASSEMBLY INSTRUCTIONS REV.OL-7284-0423 Thank you for purchasing our product FRENCH VIDEO ARABIC Scan QR to view full Scan QR to view the Scan QR to view the assembly video manual in French manual in Arabic...
-
Page 2: Main Parts List
AK-HI-PR orders: of all the parts and Parts for the 48 contiguous United States: RTA Products will replace the part free of charge, hardware listed below. while the customer is responsible for shipping costs plus any International local taxes or duties. - Page 3 RTA-B002 BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. • Please read the assembly instructions throughly and follow step by step. 30mm • Make sure you understand which hardware will be used on each step. Using the wrong size of screw, bolt or pin might M6x30 strip the threads or cause damage to the...
- Page 4 RTA-B002 THE ASSEMBLY STEPS START ON NEXT PAGE CAM BOLT AND CAM LOCK TUTORIAL THE INSTRUCTIONS BELOW ARE NOT ACTUAL ASSEMBLY STEPS This unit uses cam bolts and locks (also known as mini fixes). If you are not familiar with this kind of hardware, the below is a tutorial that explains how to use them on the steps where they are required.
-
Page 5: Assembly Steps
RTA-B002 ASSEMBLY STEPS WE RECOMMEND TO PLACE THE PIECES OVER BLANKETS TO PROTECT THEIR FINISH DURING ASSEMBLY. STEP 1 • Attach bolts D into the indicated holes on the left panel 1. • On panels 4, 5 and 6 check and make sure the cam locks on their left Hardware: side are aligned to receive the bolts. - Page 6 RTA-B002 STEP 3 Use screws A to assemble the casters 3 to panel 7 to its bottom surface Hardware: the following way: • Locking casters 3L go at the front of the panel. • Non-Locking casters 3N go at the back of the panel. M4x14 NON-LOCKING go at the back...
- Page 7 RTA-B002 STEP 5 Assemble the top shelf 8 to panels 1, 2 and 4 with bolts D as explained Hardware: in page 3. M6x40 Bolt Cam lock alignment STEP 6 Assemble the stationary tubes 9 to the side panels 1 and 2 with screws C from the sides and to the bottom panel 7 from the bottom.
- Page 8 RTA-B002 STEP 7 Place the plastic covers 11A over the tubes 9 with their threaded holes facing towards the outside. Hole facing towards the outside STEP 8 • Insert the adjustable “T” tubes 10 through the covers 11A and into the tubes 9 making sure the longer end of the square tubes faces towards the front.
- Page 9 RTA-B002 STEP 9 Assemble the main panel 12 to the tubes 10 with screws C from Hardware: underneath. M6x35 STEP 10 Assemble the protection tube 13 to the main panel 12 with screws B from underneath. Hardware: M6x25...
- Page 10 RTA-B002 STEP 11 LIFTING: Loosen the screw knobs 11B to lift, then tighten again. • If you have objects or devices on or under the main panel, use caution when adjusting the height. • Do not overtighten the screw knobs. •...
-
Page 11: Weight Limits
RTA-B002 P.10 P.10 WEIGHT LIMITS 20 Lbs (9.1 Kg) 15 Lbs (6.8 Kg) 20 Lbs (9.1 Kg) WARNINGS • Do not exceed the indicated weight limits. • Because the lift and lock system on this product consists of friction between metals, so frequent adjustments of the main top might cause scuffs on the metal tubes. - Page 12 RTA Products LLC will replace any defective part, at its discretion, and without charge to the original purchaser other than the freight from the end consumer to RTA Products.
