Connector
J17, J18 Storage interface connectors
The following table describes the LEDs on the adapter.
Table 28: LED Designations
LED Type
LED2 Yellow controller overtemperature
LED3 Green system heartbeat
eHBA 9600-24i Adapter – Connector and LED Designations
The adapter is a 155.52 (±0.13) mm × 68.77 (±0.13) mm board. The component height on the top and bottom of the
adapter complies with the PCIe specification.
Broadcom
Type
Two SFF-8654 8-port internal connectors.
Connect the adapter by cable to the storage devices.
Stays on solid to indicate that the SAS4116 device temperature sensor is over the
temperature threshold. When the device is in the proper temperature range, this LED is
off.
Indicates that the SAS4116 RoC ASIC is operating normally. This LED blinks at 1 Hz.
®
Broadcom 96xx PCIe 4.0, 24G SAS MegaRAID
Description
Description
™
and eHBA Tri-Mode Storage Adapters
96xx-MR-HBA-Tri-Mode-UG108
