When using active cables with the 9600-16e adapter, eHBA 9600-8e adapter, or eHBA 9600-8i8e adapter, you must
implement an additional step if your active cable requires that the Vman port (management interface power) be toggled.
The Broadcom adapter toggles the active cable's Vact port (active cable power), but not the Vman port after an online
firmware update or for other conditions that result in a soft reset. If your active cable requires that the Vman port be
toggled, the cable must be removed and reinserted, or power to the card slot must be cycled. If neither action is done, the
PCIe/SAS link will not be restored. If the active cable requires that only the Vact port toggle, no power cycle or cable re-
insertion is needed.
The following table shows the cable pinout for the cable that Broadcom provides for the external adapter. See
Drawings and Pinouts for drawings and pinouts of each listed cable. Use the drawings if you source your own cables.
Table 17: External Adapter Cable Pinout
Pin
A1 No Connect
A2 CINT#
A3 GND
A4 PERp0, RX0+
A5 PERn0, RX0-
A6 GND
A7 PERp3, RX3+
A8 PERn3, RX3-
A9 GND
B1 PWR
B2 CBLPRSNT#
B3 GND
B4 PERp1, RX1+
B5 PERn1, RX1-
B6 GND
B7 PERp2, RX2+
B8 PERn2, RX2-
B9 GND
Broadcom provides the following cable to use for external adapters. Use the MPN listed to order the cable from
Broadcom. If you source your own cables, use the Broadcom part number from the following table, and the drawings and
pinouts in Cable Drawings and
Table 18: External Adapter Cable
MPN Broadcom Cable Part No.
05-60009-00 5067-9643
Broadcom
Signal
Pinouts.
G4/S4 x4 8644 to x4 8644, 3M
®
Broadcom 96xx PCIe 4.0, 24G SAS MegaRAID
Pin
C1 CMICLK
C2 CMIDAT
C3 GND
C4 PETp0, TX0+
C5 PETn0, TX0-
C6 GND
C7 PETp3, TX3+
C8 PETn3, TX3-
C9 GND
D1 PWR
D2 MGTPWR
D3 GND
D4 PETp1, TX1+
D5 PETn1, TX1-
D6 GND
D7 PETp2, TX2+
D8 PETn2, TX2-
D9 GND
Cable Description
™
and eHBA Tri-Mode Storage Adapters
Cable
Signal
Backplane Connector
Two x4 SFF-8674
