Audio Connections
This screen allows selection of groups to receive Background Music, Time Tones and Emergency Tones. This
sample system consists of a "Main Board + Expansion 1" so eight groups are available to receive audio connections.
(Each group contains six stations).
Group 1
Group 2
Group 3
Group 4
Group 5
Group 6
Group 7
Group 8
Click on the tab of the desired feature to program zones. Click on each group button to receive the audio
connection. If all groups are to receive an audio connection for the specific feature, select Include All.
The zones for each feature:
BGM, Time Tone and Emergency, are selected in the same manner.
Defaults: BGM
Time Tone
Emergency
After zones for each feature have been selected, press the OK button.
Stations 1, 2, 3, 4, 5, 6
Stations 7, 8, 9, 10, 11, 12
Stations 13, 14, 15, 16, 17, 18
Stations 19, 20, 21, 22, 23, 24
Stations 25, 26, 27, 28, 29, 30
Stations 31, 32, 33, 34, 35, 36
Stations 37, 38, 39, 40, 41, 42
Stations 43, 44, 45, 46, 47, 48
- All Off
- All On
- All On
7
Main Board
Main Board
Main Board
Main Board
Expansion 1
Expansion 1
Expansion 1
Expansion 1
