INSTALLATION OF THE OPTION BOARD

The Option Board must first be installed on the Control Unit Board (See Figure 1).
WARNING: Disconnect main power before servicing.
Remove the side plate and top cover of the Control Unit and set aside.
Slide small side plate upward to provide opening for Option Board connector (See Figure 1).
Align J3 on the Option Board directly over J1 on the Control Board
Align J4 on the Option Board directly over JP2 on the Control Board.
Press Option Board firmly in place to make sure connectors are seated properly.
Replace the top cover and side plate of the Control Unit and plug in the power supply.
Plug PC Communication Cable (included) into P1, PC Programming Port (located on the Option Board - See
Figure 1).
The V-2926 Option Board requires the use of the PC Programming Tool to access the various features it provides.

INSTALLATION OF THE PROGRAMMING TOOL

Minimum Computer Requirements for the Valcom V-2924A Programming Tool:
Hardware:
80486 (higher is recommended)
Hard drive with 30 Mbytes free
Mouse
8 Mbytes of RAM (more is recommended)
1 available serial communication port
Operating System:
The Programming Tool is 32-bit and requires Windows 95, Windows 98, or Windows NT 4.0.
The Rev 2 Programming Tool is compatible with previous versions of hardware, however, the current hardware
is not compatible with previous versions of the Programming Tool.
The programming tool software is furnished on 1.4 MB disks and must be installed to the hard drive. To install the
software:
On the taskbar, click the Start button
Insert disk 1
Select Run
Type a:\Setup (Assuming a: is the disk drive being used)
Follow on-screen instructions for full installation, changing disks as the prompt requests
The Valcom V-2924A Programming Tool will automatically appear in the Programs list
