Analyzer Set-up

Press the Set button [5] to program the analyzer.
The display will show the Operations Screen.
Operations Screen
1) Test Ref:
2) Test Number:
3) Time and Date:
4) Result Presentation Options:
5) Type Test:
6) Test Options:
Press a Key to Choose or 0 to Exit
To change analyzer settings, follow this sequence:
1. Test Reference—Press [1], enter your reference
details (up to 16 characters), and press [Return]
2. Test Number—Press [2], enter a number,
and press [Return] (test numbers increase automatically)
3. Time and Date—Press [3], set time and date using key-
pad, and press [Return]
A cumulative cycle count is displayed on the Time and
Date screen; this value increases automatically by 1 each
time a test is taken, and cannot be adjusted or reset.

Test Set-up

5. Test Type—Press [5] one or more times to
select test type.
Te s t Ty p e s
Normal: Single test with 15ml sample volume.
Dynamic: Comprehensive triple test with results average;
30ml sample volume comprising three 10ml sampling and
emptying cycles. Results are displayed on completion of
three tests, including emptying cycles.
Triple/Bottle Sampling: Triple test with resultsaverage;
faster than Dynamic test; 24ml sample volume comprising
three individual 8ml samples tested consecutively.
For bottle sampling instructions, see pages 12–13.
Continuous Sampling: For instructions, see pages 6–7.
Short-Single Test: 8ml sample volume; faster than Normal
test; not recommended for oil samples cleaner than ISO
17/15/12 (NAS6).
4 Vickers by Danfoss Target-Pro 2 Analyzer and Sampler Operation Manual V-PP-MC-0002-E July 2023
4. Result Presentation Option—Press [4], then
press keys to select options: Press the relevant
key to switch between option selections:
1) ISO format, Repeat 1) NAS format
2) Print detailed counts, Repeat 2) Do not print
detailed counts
3) Print test reference, Repeat 3) Do not print test
reference
4) Automatically print results, Repeat 4) Do not
automatically print results
5) Print space for notes, Repeat 5) Do not print spaces
for notes
6. Language number (four options):
Language 0 (default) . . . . . .English
Language 1 . . . . . . .
Language 2 . . . . . . .
Language 3 . . . . . . .
To select language, press 6, enter chosen value (such as
1 for Italian), and press Return; to use a newly selected
language, you must switch the analyzer off and on again.
6. Test Options—Press 6 to display Test
Operations screen.
Test Operations Screen (continuous test only)
Test Operations Screen
1) Minutes Between Tests:
2) ISO Target Level:
3) NAS Target Class:
4) Do Not Log Every Test:
5) Confirm Cleanliness Level
Press a Key to Choose or 0 to Exit
These options only apply to the Continuous Test; ignore if
other test types are selected. For detailed continuous sam-
pling instructions, see pages 6–7.
. . . . . .Italian
. . . . . .French
. . . . . .German
