Table Of Contents - Danfoss Vickers Target-Pro 2 Operation Manual

Target-Pro 2
Laser Particle Analyzer
User Guide:
September 2004
2 Vickers by Danfoss
C o n t e n t s
Operating Precautions
Introduction
ISO Cleanliness Code
Target-Pro 2 Operation
Key and Connector Diagrams
Online Operation
Analyzer Set-up
Test Set-up
Running a Test
Shutting Down
Continuous Sampling
External W iring Details
Memory Recall
Battery Charging / Printer Paper
Software Installation
ISO 4406 Cleanliness Code System
NAS 1638 Cleanliness Code System
Hydraulic Component Manufacturers Recommendations
Hydraulic System Target Cleanliness Levels
110ml Bottle Sampler for Target-Pro 2
Appendix
Specifications and Part Numbers
Troubleshooting
Danfoss reserves the right to alter speci cations without notice. Except as permitted by such license,
no part of this publication may be reproduced without prior written permission of Danfoss.
O p e r a t i n g P r e c a u t i o n s
Battery
• The Target-Pro 2 uses a nickel-cadmium (NiCd) battery.
Charge it for at least 24 hours before first use.
• For optimum performance, fully discharge and recharge
the battery once a month: Leave the Target-Pro 2
switched on until the LCD screen goes blank, then switch
off the Target-Pro 2, connect the charging adapter, and
allow it to charge the battery for 24 hours.
• To prolong battery life, switch off the analyzer when it is
not in use.
Internal Cleaning
Do not clean the Target-Pro 2 or Bottle Sampler with ace-
tone or other solvents that are not compatible with nitrile
seals. The recommended cleaning fluid for internal flushing
is mineral spirits.
Target-Pro 2 Analyzer and Sampler Operation Manual V-PP-MC-0002-E July 2023
