Stinger HEIGH10 UN1810E-FT3 Installation Manual

Integrated infotainment touch screen solution for fiat ducato series 7 2014-2021 open dash vehicles only

INSTALLATION GUIDE

INTEGRATED INFOTAINMENT TOUCH SCREEN SOLUTION FOR

FIAT DUCATO SERIES 7 2014 - 2021

OPEN DASH VEHICLES ONLY

PART NUMBER: UN1810E-FT3

If you would like to download a digital copy of this manual, or any other product, then please visit the

www.StingerElectronics-EU.com website.

This manual is considered correct at the time of printing but is subject to change.

For the latest manuals & updates, refer to our website.

Legal Information

Please consult the relevant road traffic laws governing the country in which this product is being operated.

No liability is accepted for material damage, loss or personal injury, directly or indirectly, from installation and

operation of this product. This product should only be operated when safe to do so.

StingerElectronics-EU.com

Table of Contents

Need help?

Do you have a question about the HEIGH10 UN1810E-FT3 and is the answer not in the manual?

Page 1 INSTALLATION GUIDE INTEGRATED INFOTAINMENT TOUCH SCREEN SOLUTION FOR FIAT DUCATO SERIES 7 2014 - 2021 OPEN DASH VEHICLES ONLY PART NUMBER: UN1810E-FT3 If you would like to download a digital copy of this manual, or any other product, then please visit the www.StingerElectronics-EU.com website.
Page 2 The components of this kit are compatible for the Fiat Ducato Series 7 2014 - 2021 , open dash vehicles only. CONTENTS • HEIGH10® unit with fitting accessories and wiring • Black double DIN fascia plate (with accessories) • Vehicle retention interface with plug-and-play harness • Vehicle specific antenna adapter (AM/FM) • Stinger stereo patch lead • Instruction manual www.stingerelectronics-eu.com...
Page 3 FITTING GUIDE Take the HEIGH10® components and begin to assemble the core components in accordance with the “Installation Manual” that comes with unit. HEIGH10 ASSEMBLY FITTING GUIDE FASCIA PLATE SET-UP 1. With the HEIGH10® unit configured correctly, attach the fascia brackets to the relevant sides of the radio module using the screws within the kit.
Page 4 AGREEMENT: End user agrees to use this product in compliance with the instructions and terms of use and with all laws. STINGER provides instructions and safety warnings with respect to this product and disclaims all liability for any use not in conjunction with those instructions or other misuse of its product.
