e Incorrect placement can also reduce the acquired sensor signal, and therefore compromise
performance. Select an alternate site (toe) or use a FLEXISENSOR® SD if the sensor can
not be placed on the patient's finger correctly or if the fingernails interfere with the
acquisition of a reliable signal.
e Use of the DATASENSOR is not recommended for long-term monitoring (4-6 hours). For
monitoring situations exceeding 4-6 hours, either reposition the DATASENSOR every
2-4 hours to a different site (finger/toe) or use a FLEXISENSOR® SD with its appropriate
bandage.
© Do not over-tighten the sensor bandages. Excessive pressure on the monitoring site can
affect SpO2 readings and may reduce readings below true SpOz. Excessive pressure can
also result in pressure necrosis and other skin damage.
e Sensor configuration provides virtually uninterrupted monitoring during following
situations:
Electro-cautery Noise - Electro-cautery noise rejection is designed into the sensors.
Motion Artifact - The monitor's software adjusts the "averaging period" increasing it
during motion and reducing it during inactivity. This decreases the number of
monitoring interruptions and false alarms.
Weak Peripheral Pulses - The monitor's gain is automatically increased to track
pulses on patients with decreased peripheral perfusion.
Datascope SpO2 Sensor Selection Table
Sensors Large Adult Pediatric | Infant Adult Datasensor
Adult (LA)|(A) (P) 0) Ear (AE)
Approximate >80kg/ 0 - 90kg/ |10- 45- >40kg/ |40+ kg/
Patient Weight |>1761bs 166-198 |40kg/ 10kg/ >88 jbs |90+ jbs
Ibs 22-88 |10-22
Ibs Ibs
Where Used Fingers, Fingers, |Fingers, |Feet, Adult Fingers, Toes
Toes Toes Toes Palms, Ear
Big Toes
Long or Short Long & Long & |Long& |Long& |Long& |Short Term
Term Moni- Short Short Short Short Short
toring Term Term Term Term Term
Electro-Surgical | Included ¡Included [Included ¡Included | Included | Included
Interference
Suppression
(ESIS)
Reusable Yes Up to |Yes Up to | Yes Up |YesUp |YesUp | Yes
20 Uses |20Uses |to 20 to 20 to 20 6-Months
Uses Uses Uses
Bandage Type | Adhesive, | Adhesive, | Adhesive, |Non- . | Adhesive | Disposable
Disposable | Disposable | Disposable | Adhesive*
Part |Sensors | 0998-00-0 |0998-00- | 0998-00- | 0998-00- | 0998-00- | 0600-00-0026-01
493 076-06 0076-05 (0076-04 (0074-03 | 0074-05 _|(3' sensor cable)***
Bandages| 0683-00-0 | 0683-00- | 0683-00- | 0683-00- | N/A N/A
409-01 0409-02 |0409-03 [0415
* <Non-adbesive bandages ave recommended for premature infants to minimize prenatal shin damage.
** See Accessories, Chapter 5, for more detailed information.
**%* Additional choices: 0060-00-0026-02 (10' sensor cable), 0020-00-0071-01
(3° sensor cable plus 7° extension cable).
1-36
Chapter 1, Operation
