- Page 1 S15L Pro In-Line Indicator with ModBus® Instruction Manual Original Instructions p/n: 235708 Rev. A October 10, 2023 © Banner Engineering Corp. All rights reserved.
-
Page 2: Table Of Contents
Chapter 3 ModBus® Register Map ..................7 Chapter 4 Specifications FCC Part 15 Class B ....................................12 Industry Canada ICES-003(B)..................................12 Dimensions ......................................... 12 Chapter 5 Accessories Cordsets ........................................13 Brackets........................................14 Quick-Disconnect Cap....................................14 Chapter 6 Banner Engineering Corp Limited Warranty............ 15 ... -
Page 3: Chapter 1 Features
Connect directly to a compatible sensor or anywhere in the ModBus network for easy visual indication • ModBus® gives full access to color, flashing, and intensity settings Models Model Housing Style Control Connector Integral 4-pin M12 male/female quick- S15LPSQ Serial ModBus RS-485 disconnect connector October 10, 2023 © Banner Engineering Corp. All rights reserved. - Page 4 Blank page ...
-
Page 5: Chapter 2 Wiring
Chapter 2 Wiring 4-pin M12 Male 4-pin M12 Female Wire Color Description Brown 12 V DC to 30 V DC Blue DC Common Black RS-485 (-) White RS-485 (+) October 10, 2023 © Banner Engineering Corp. All rights reserved. - Page 6 Blank page ...
-
Page 7: Chapter 3 Modbus® Register Map
3303 Pulse Pattern 2 = Three Pulse 3 = SOS 4 = Random 0 = Slow 1 = Medium 3303 3304 Speed 2 = Fast 3 = Custom Flash Rate 3304 3305 Reserved 0 3305 3306 Reserved 0 3306 3307 Reserved 0 Continued on page 8 October 10, 2023 © Banner Engineering Corp. All rights reserved. - Page 8 0-255, 0-255 (Two 8-bit 3410 3411 numbers) 3411 3412 Custom Color 2 Blue 0-255 3420 3421 Custom Intensity 0-100 3421 3422 Custom Speed 5-255 0 = Off 3422 3423 Restrict To Gamut 1 = On October 10, 2023 © Banner Engineering Corp. All rights reserved.
- Page 9 Device ID: the Modbus individual node 6100 6101 1-247 12 = 1200 24 = 2400 6101 6102 Baud rate 48 = 4800 96 = 9600 192 = 19200 0 = None 6102 6103 Parity 1 = Odd 2 = Even 1 = 1 6103 6104 Stop Bits 2 = 2 3 = 1.5 October 10, 2023 © Banner Engineering Corp. All rights reserved.
- Page 10 Blank page ...
-
Page 11: Chapter 4 Specifications
Wiring Protection (A) Protection (A) (AWG) (AWG) Refer to the CIE 1931 (x,y) Chromaticity Diagram to show equivalent color with indicated color coordinates. Actual coordinates may differ ± 5%. October 10, 2023 © Banner Engineering Corp. All rights reserved. -
Page 12: Fcc Part 15 Class B
Dimensions All measurements are listed in millimeters [inches], unless noted otherwise. 57.8 [2.27] 27.9 [1.1] 15.0 [0.59] M12 X 1 - 6H M12 X 1 - 6g October 10, 2023 © Banner Engineering Corp. All rights reserved. -
Page 13: Chapter 5 Accessories
M12 x 1 ø 14.5 [0.57"] MQDEC-430SS 9.14 m (30.2 ft) Male Male Straight/ Female Straight 44 Typ. [1.73"] M12 x 1 MQDEC-450SS 15.2 m (49.9 ft) ø 14.5 [0.57"] 1 = Brown 2 = White 3 = Blue 4 = Black October 10, 2023 © Banner Engineering Corp. All rights reserved. -
Page 14: Brackets
Ø 4.9 LMBS15SP Ø 9.5 • Attaches to S15 housing Ø 15.0 • White polypropylene 26.2 • Clearance for M5 or #10 hardware • Pack of five 23.5 15.0 Quick-Disconnect Cap ACC-CAP M12-10 • 10 Caps • Seal and protect exposed, unterminated cascade quick-disconnect connectors October 10, 2023 © Banner Engineering Corp. All rights reserved. -
Page 15: Chapter 6 Banner Engineering Corp Limited Warranty
Banner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. - Page 16 LinkedIn Twitter Facebook © 2023. All rights reserved. www.bannerengineering.com...
