- Page 1 User manual MH600 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5 DMX Channels …………………………………………………………………………………6-10 Dimension …………………………………………………………………………………………10 Trouble Shooting…………………………………………………………………………………11 Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu Menu Operation On the base of the control panel offers a number of features, such as setting DMX fixture address, switch the lamp, run the test program, the mode selection. Dmx Address 001-512 Channel mode 17CH/27CH/99CH/108CH/168CH Fixture Run Mode DMX/Auto Tilt Invert Close/Open... -
Page 6: Dmx Channels
4.DMX Channels 17CH Mode Channel Function DMX value Details Tilt 0 - 255 Tilt Tilt Fine 0 - 255 Tilt Fine Zoom 0 - 255 zoom Dimmer 0 - 255 0-100%line dimmer Wash STROBE 0 - 255 Wash STROBE Line-W STROBE 0 - 255 Line-W STROBE Line- RGB STROBE... - Page 7 CH14 Wash-Color macro 0 - 255 Wash-Color macro CH15 Wash-Built-in effects 0 - 255 Wash-Built-in effects CH16 Wash-Built-in effects speed 0 - 255 Wash-Built-in effects speed CH17 Line-CW 0 - 255 Line-CW CH18 Line-WW 0 - 255 Line-WW CH19 Line -CTO 0 - 255 Line -CTO CH20...
- Page 8 CH47 Wash-Blue 10 0 - 255 Blue 10 CH48 Wash-White 10 0 - 255 White 10 CH49 Line W-CW 1 0 - 255 Line W-CW 1 CH50 Line W- WW 1 0 - 255 Line W- WW 1 CH51 Line W-CW 2 0 - 255 Line W-CW 2 CH52...
- Page 9 CH49 Line W-CW 1 0 - 255 Line W-CW 1 CH50 Line W- WW 1 0 - 255 Line W- WW 1 CH51 Line W-CW 2 0 - 255 Line W-CW 2 CH52 Line W- WW 2 0 - 255 Line W- WW 2 ……...
-
Page 10: Dimension
…… …… …… …… CH45 Wash-Red 10 0 - 255 Red 10 CH46 Wash-Green 10 0 - 255 Green 10 CH47 Wash-Blue 10 0 - 255 Blue 10 CH48 Wash-White 10 0 - 255 White 10 CH49 Line W-CW 1 0 - 255 Line W-CW 1 CH50... -
Page 11: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
