Existing SPM online systems
Service laptop
FSS
Field Support
Software
Ethernet /
SD card
System Unit 1

System Description

The Intellinova Compact Ex system is a permanently
®
installed, online machine condition monitoring sys-
tem. It is handled by the comprehensive software
Condmaster Ruby or Condmaster
®
the system, collects, stores, and evaluates the measuring
results. Via Ethernet, the Intellinova system is connected
to a computer with the software Condmaster
communication program LinX. The measuring assign-
ments are set up in Condmaster
measuring assignments to and reads the result file from
the Intellinova System Unit. Measuring results are stored
in a historical database. System functionality and trans-
ducer lines are automatically monitored for malfunctions.
The core of the system is the SPM Instrument software,
Condmaster , which receives the measuring results from
®
all SPM Instrument devices for evaluation and presenta-
tion. Based on extensive empirical data, international
standards and machine statistics, the evaluation result is
an easy-to-understand color code, highlighting potential
trouble spots. By calibrating and adjusting limit values,
the automatic evaluation process can be tuned with great
precision to get an immediate, reliable diagnosis. Intel-
linova implements OPC™ Data Access, through which
process control data can be transferred seamlessly to and
from any data source, such as DCS or SCADA systems,
System Description
Data base
System Unit 2
Nova, which controls
®
, and the
®
and LinX transmits the
®
– 4 –
OPC
Data Access
Client /
Server
Ethernet
System Unit 3
PLCs, databases, gauges, spreadsheets etc. to any OPC
compliant application. Intellinova
designed in every aspect, made for harsh and potentially
explosive environments and long-term use.

Conformity with Standards

The explosion-proof Intellinova
the requirements of EN 60079-0, EN 60079-15 and EN
60079-31. They have been developed, manufactured
and tested in accordance with ISO 9001 and EN ISO/
IEC 80079-34.
Customer systems
Process
OPC
Control
Client /
System
Server
Compact Ex is robustly
®
Compact Ex units meet
®
