Wi-Fi Ethernet Unit (Option) - SPM intellinova compact INS06 Ex Assembly, Installation And Operation Instructions

Omni-directional
antenna with
5 m cable
The option includes a wireless Ethernet unit
IND01 Ex
mounted on the cabinet lid and internal wiring. An ex-
ternal omni-directional antenna and a 5 m antenna cable
are included.
Technical Specifications IND01 Ex
Fonctions
Format
Dimensions
Support
Maximum Speed
Ethernet link
Radio link
Frequency range
Radio Modem (AD HOC)
Rapid roaming
Antenna connectors
Nominal range
Security
Number of Wi-Fi clients
Administration
Power supply
Power consumption
WirFi Ethernet Unit (Option)
Ethernet wireless Wi-Fi bridge, bridge router, access Point, repeater (WDS) & virtual cable
Universal mounting box (wall and Din Rai)
L:103 x W:67 x H:24 mm
MODBUS/TCP, PROFINET & Ethernet/IP wireless gateway
108 Mbps
100 Base Tx (RJ45) 10/100 compatible
Triband wireless Wi-Fi IEEE 802.11a/b/g/h & Super AG
2.4 / 5 / 5.4 GHz
Bridge mode
< 50 mS
RP-SMA
300 m, open field (with built-in antennas)
WPA-PSK, WPA2-PSK, WEP 64/128 bits, IEEE 802.1X (RADIUS) MAC addresses filtering
SSID broadcast control
30 (in AP mode)
Web browser SNMP, ACKSYS NDM
+9VDC to +48VDC, 3-point PHOENIX connector
3.5W typical
– 18 –
Antenna connected
to 'MAIN'
Inside of the lid
The System Unit is connected via a 10/100 Ethernet
switch on the Wi-Fi Ethernet unit. For configuration of
the Wi-Fi unit, see the user guide from the manufacturer
(ACKSYS ).
DTUS061
Wi-Fi Ethernet unit
