Table Of Contents - SPM intellinova compact INS06 Ex Assembly, Installation And Operation Instructions

Contents
Safety Arrangements ........................................ 2
Installation Precautions ..................................... 3
System Description ........................................... 4
Conformity with Standards ............................... 4
Mechanical Installation ..................................... 5
System Unit - Overview .................................... 6
Electrical Installation ......................................... 7
Cable Entries ................................................. 7
Selection of Cables ........................................ 7
Power Supply ................................................. 8
Intrinsic Safety Earth ...................................... 9
Network Connection ...................................... 9
Connection to PC .......................................... 9
Bearing Monitoring ........................................ 11
Connection of Shock Pulse Transducers ....... 11
Mounting TNC Connector 93022 ................ 12
Installation Instructions
Vibration Monitoring ..................................... 13
Connection of Vibration Transducers ........... 13
Connection to IS-earth ................................. 13
Connection of Digital Inputs, DI / RPM ............ 14
Connection of Analog Inputs, AI .................... 15
Connection of Digital Outputs, DO ................ 16
SD Memory Card ............................................ 17
Configuration ................................................. 17
Wi-Fi Ethernet unit (Option) ........................... 18
Service and Maintenance ................................ 19
Technical Specifications INS 06 Ex .................. 20
Part Numbers ................................................. 21
Approved Spares and Accessories ................. 21
