Camera Access Setup - Amcrest IP8M-VD2893EW-AI User Manual

Note: Due to specific hardware limitations within your camera it is important to note that these
devices will not be able to automatically pan/tilt or pivot in either the app or via the web UI on
a computer.
For this reason, it is imperative to make sure to mount the cameras properly and position them as
efficiently as you can to the areas you wish to monitor. All positioning actions to the camera will
have to be performed manually.
To install the camera onto a wall, follow the steps below:
1.Use a Torx/Hex wrench (included) to open the dome enclosure by unfastening the three inner
hex screws on enclosure.
2.Place the installation sticker on the wall or ceiling surface that you wish to mount your camera.
3.Using the X's on the installation sticker, drill 3 holes to allow for the insertion of the included
expansion bolts.
4.If the camera's cable will be exiting through the wall or ceiling surface, please be sure to drill an
exit hole and pull the cable through.
5.If the camera's cable will be exiting through the side of the camera, route the cable through the
U-shaped channel on the side of the enclosure.
6.Align the camera with the installation sticker, then line up the 3 screw holes in the camera
pedestal to the three plastic expansion bolts on the installation surface. Put the three included
screws through the camera then insert them into the expansion bolts firmly.
7.Adjust the camera in the position that you want it to be in, then reattach the dome body to the
base of the camera.
Note: Range of lens: vertical (0°～+65°), horizontal (0°～+355°). When adjusting the camera into
position, please ensure that the camera's enclosure does not block the image or cause reflection
of IR light.

Camera Access Setup

This section will provide information on how to setup and access your camera through the following
methods:
•
Local PC (Web User Interface (Web UI), Amcrest Surveillance Pro, etc.)
•
Amcrest View Pro app
•
Amcrest Surveillance Pro (amcrest.com/downloads)
•
Amcrest Cloud
Default Username and Password
To login to the system for the first time, use one of the following default username/password
combinations. Once you have successfully logged in, it is highly recommended to change the
password for security reasons.
Username: admin
Password: admin
