Amcrest IP8M-VD2893EW-AI User Manual page 30

When the setup button is clicked, a live stream of the video is shown. The user can then set up to 4
regions, each with their own region name, sensitivity (1-100), and threshold (1-100). Each region
has a specific color, and the region selector tool is displayed when the mouse is moved to the top of
the screen.
Sensitivity is the amount of change required to increase the motion detected by a percentage.
The lower the sensitivity, the more movement is required to trigger an alarm.
Threshold is the level that the motion detection needs to reach to trigger an alarm. The lower
the threshold, the more likely that motion will trigger an alarm.
To designate a zone, click and drag the mouse over the area desired. When a colored box is
displayed over the live feed, that area is now enabled for motion detection.
After the motion detection zone is set, click the enter button to exit the motion detection screen.
Remember to click the save button on the motion detection settings screen, otherwise the
motion detection zones will not go into effect. Clicking the cancel button to leave the motion
detection zone and will not save the zone setup.
• Record: This checkbox allows the user to enable the camera to record video when a motion
detection alarm is triggered.
• Record Delay: This field specifies in seconds how long the delay between alarm activation and
recording should be.
• Relay Out: This checkbox allows the user to enable the camera to trigger a connected alarm
(connected to the alarm port on the back of the camera) when a motion detection alarm is triggered.
• Alarm Delay: This field specifies in seconds how long the delay between alarm activation and Relay
alarm activation should be.
• Send Email: This checkbox allows the user to enable the camera to send an email when a motion
detection alarm is triggered.
• Snapshot: This checkbox allows the user to enable the camera to take a snapshot when a motion
detection alarm is triggered.
To reset to default settings, click the Reset Defaults button. To refresh the page, click the Refresh
button. To save the settings, click the Save button.
Video Tampering
This tab allows the user to modify video tamper settings.
Below is an explanation of the fields on the Video Tamper tab:
•
Enable: This checkbox enables a video tamper alarm for the camera.
•
Schedule: Clicking this button opens a weekly schedule that can be used to set times.
30
