- Page 1 BHMS-104 HotPlate Magnetic Stirrer Thank you very much for Choosing Biolab products. Please read the “Operating Instructions” and “Warranty” before operating this unit to assure proper operation.
- Page 2 HotPlate Magnetic Stirrer BHMS-104 Index 1. Safety Instruction and Installation....................03 2. User Instruction..........................06 3. Troubleshooting and Maintenance..................13 4. Warranty.............................14 www.biolabscientific.com...
-
Page 3: Safety Instruction And Installation
HotPlate Magnetic Stirrer BHMS-104 Safety Instructions and Installation 1.1 Safety Instructions Warning! Read the operating instructions carefully before use. Ensure that only trained staff works with the instrument. • Risk of burn! Caution when touch the housing parts and the hotplate which can •... - Page 4 HotPlate Magnetic Stirrer BHMS-104 g. If the case of the stirrer bar is PTFE, please note: - Elemental fluorine, three fluoride and alkali metals will corrode the PTFE and Halogen alkalies make it expand at room temperature - Molten alkali, alkaline earth metals or their solution, as well as the powder in second and third ethnic of the Periodic Table of Elements will have chemical reaction with PTFE when temperature reaches 300 ~ 400°C.
- Page 5 HotPlate Magnetic Stirrer BHMS-104 Picture 1 This device is not suitable for using in residential areas or other constraints mentioned in 1.1. 1.3 Inspection 1.3.1 Receiving Inspection Unpack the equipment carefully and check for any damage which may have arisen during transport.
-
Page 6: User Instruction
HotPlate Magnetic Stirrer BHMS-104 User Instruction 2.1 Functions 2.1.1 Technical Parameters Capacity 20 L Stirring Positions Speed Range 100-1500 rpm Temperature RT-340°C Permissible Ambient Temperature 5-40°C Temperature Increment 1°C Control Accuracy of Work Plate ±1(<100°C), ±1%(>100°C) Temperature Accuracy ±0.1°C Safety Temperature 360°C... - Page 7 HotPlate Magnetic Stirrer BHMS-104 2.1.2 Control Picture 2 Picture 3 www.biolabscientific.com...
- Page 8 HotPlate Magnetic Stirrer BHMS-104 Items Descriptions Turning the knob, switches the parameters setting interface, followed by Temperature setting, Speed Function switch knob setting, Timer setting, switching cycle. Pressing the knob turns the three setting options on/off. At the parameter setting interface, set the Parameter setting knob parameter by turning the knob.
- Page 9 HotPlate Magnetic Stirrer BHMS-104 Characters Descriptions Displays temperature when the heating function is switched Temp & °C Displays stirring speed when the stirring function is switched Stir Displays HOT warning if the plate temperature is above 50°C after switching OFF the heating function.
- Page 10 HotPlate Magnetic Stirrer BHMS-104 Warning ! Do not remove the vessel when the instrument is operating. 2.3 Function 2.3.1 Heating The device is controlled by digital temperature control technology, which has two separate safety circuits. The hotplate is kept at a constant temperature by a digital control circuit. The hotplate temperature can also be controlled from a separate, adjustable safety circuit.
- Page 11 HotPlate Magnetic Stirrer BHMS-104 1) Working with the PT1000 external temperature sensor Picture 5 The PT1000 external temperature sensor is the manufacturer’s optional accessory. If the sensor is plugged in, “Probe” will be shown on the digital display to indicate the sensor is operating. The setting value of external temperature sensors and actual temperature are displayed.
- Page 12 HotPlate Magnetic Stirrer BHMS-104 2.3.2 Stirring The “stirring” function is switched on or off via rotating stirring knob. The speed is set on the knob (100 to 1500 rpm in steps of 10 rpm). When both the heating function and stirring are switched on and the above operations are completed, the LCD will shift to the speed value and revert back to the temperature value in about 5 seconds.
-
Page 13: Troubleshooting And Maintenance
HotPlate Magnetic Stirrer BHMS-104 Troubleshooting and Maintenance 3.1 Faults 1) Instruments can’t be powered ON Check whether the power line is unplugged Check whether the fuse is broken or loose 2) Fault in power during self-test Switch OFF the unit, then switch ON and reset the instruments to factory default setting. -
Page 14: Warranty
HotPlate Magnetic Stirrer BHMS-104 Before using other method for cleaning or decontamination, the user must ascertain with the manufacturer that this method will not harm the instrument. Wear the proper protective gloves during cleaning of the instrument. Note: a. Electronic equipment cannot cleaned with a detergent cleaner b. - Page 15 BIOLAB SCIENTIFIC LIMITED 3660 Midland Avenue, Suite 300, Toronto, Ontario M1V 0B8, Canada +1 707 533 1445 info@biolabscientific.com www.biolabscientific.com...
