Installation and network

1 Preparation
1.1 HDMI HD image transmission（1080P） or Network port HD image
transmission is a must
1.2 Choose the communication mode of the control pod, the pod can be
controlled by S.BUS, serial port and network, serial port and network need to
develop the corresponding software through the protocol by user.
1.3 Supported TF card types (this pod TF memory card does not support hot
swapping). Use a Class10 or UHS-1 and above TF card to ensure proper video
recording.
1.4 Power supply, the pod uses a power supply voltage of DC12v ~ 24v (3S ~
6S), in order to ensure the stability of the pod, it is necessary to ensure more than
30w power supply power, transient power to meet more than 60w.
2 Installation
2.1 The fixing kit, damping ball and pod main body are assembled together,
and different types of damping balls and quantities are selected according to the
size of the aircraft rotor etc.
2.2 After assembling the pod, then mounting it to the flight platform through
the fixing hole.
2.3 Insert TF card.
2.4 Video connection through network.
2.5 Connect the control interface, S.BUS or TTL serial port or network.
3. IP connection
The default IP address is 192.168.1.100, network video surveillance and IP
address modification can use IE; in addition, it also supports rtsp stream access, and
can use video software such as vlc media player (VLC) to monitor video.
RTSP stream address：
Main sterm: rtsp：// camera IP ：554/majorAV（e.g.：
rtsp://192.168.1.100:554/majorAV）
Sub stream : rtsp：// camera IP ：554/minorAV（e.g.：
rtsp://192.168.1.100:554/minorAV）
