Series 51 Electrohydraulic Proportional Controls Service Manual
4. Install the spring guide (M20).
5. Install pin (M26). and Install piston (M24).
6. Make sure pin (M26) fits into 4-way valve (F32).
C
Caution
Read BLN-10181 for minor repair instructions for the F32 4-way valve, threshold spring, and ramp
spring components, if their repair is necessary
7. Using petroleum jelly to hold them in place, install new O-rings (G36, G38, G42) or gasket (G420).
8. Install screws (M10). Refer to table for wrench size and torque.
9. Lubricate and install new O-ring (M50A).
10. Install plug (M50). Using a 1/8-inch internal hex wrench, torque to 6 N•m [4 lbf•ft].
11. Install check ball (M47).
12. Install the check ball seat (M46). Using a 5mm internal hex wrench, torque to 8 N•m [6 lbf•ft].
Newer units have a check valve assembly at M46.
13. Lubricate and install the new O-ring (M48A).
14. Install plug (M48). Using a 1/4-inch internal hex wrench torque to 37 N•m [27 lbf•ft].
15. Install gasket (M14). Install cover block (M12).
16. Install screws (M28). Using a 4 mm internal hex wrench torque to 6.4 N•m [4.7 lbf•ft].
17. Install adjuster screw (M18). Adjust to previously marked position.
18. Using a 3 mm internal hex to hold screw (M18) in place, install locknut (M16). Torque to 15 N•m [11
lbf•ft].
19. Install the PCP (M30).
20. Using a 5/32-inch internal hex wrench install screws (M32) and torque to 6 N•m [4 lbf•ft].
11009448 • Rev BA • July 2014
