Service Manual
A7, L1, L2, L7 Controls
22
Series 51 Electrohydraulic Proportional Controls Service Manual
Controls
F32
G42
G38
M18
O-ring M1A
Solenoid
stem
M1
M1 coil
O-ring
Plastic
nut
Legend
Item
M22
(80, 110)
M22
(160, 1250)
Item
M16
M18
M12
3. Using a 1/4-inch internal hex wrench, remove the plug assembly (M16).
4. Remove and discard O-ring (M16A).
11009448 • Rev BA • July 2014
G38
G42
M18
M10
M16
M22
Wrench size
8 mm internal hex
10 mm internal hex
Wrench size
1/4 internal hex
1/8 internal hex
5 mm internal hex
G420
M12
M16A
P101 915
Torque
78 Nm [58 lbf•ft]
110 Nm [81 lbf•ft]
Torque
37 Nm [27 lbf•ft]
6 Nm [4 lbf•ft]
11 Nm [8 lbf•ft]
