Table 2-2 Enterasys Wireless AP3620 and AP3640 Installation Components
Component
1
2
3
4
5
6a
6b
7
8
9
10
Description
Antenna connector (Reverse Polarity Type-N jack)
Cable from antenna to lightning protector (Reverse Polarity Type-
N plugs on both ends)
Lightning protector (Reverse Polarity Type-N jacks on both ends)
Lightning protector ground terminal
Cable from lightning protector to AP pigtail (Reverse Polarity
Type-N plugs on both ends)
AP pigtail (Reverse Polarity SMA plug to Reverse Polarity Type-N
jack)
AP pigtail (Reverse Polarity SMA plug to Reverse Polarity Type-N
plug)
AP pigtail connector to AP external antenna connector
AP3620/AP3640 Access Point
Terminator cap used when the AP does not perform wireless data
transmission on this connector
Connection to switch
