Figure A-14
WS-AO-2S08360
2.4 GHz ISM omnidirectional base station antenna. This antenna was formerly distributed by
Enterasys as RBTES-BG-M08M; intended for use with legacy Wireless 802.11a/b/g RoamAbout
Outdoor APs.
Specifications
Table A-8 WS-AO-2S08360 Specifications
Specification
Frequency
Gain
Impedance
Vertical beamwidth at 1/2 power
Azimuth (3 dB beamwidth)
Bandwidth at 1:5:1 WSWR
VSWR
Polarization
Input Impedance
Mounting Style
Weight
Height
WS-AO-5D16060 Elevation Radiation Pattern Midband Freq. 5.35 GHz
-30
-45
-60
-75
-90
-105
-120
-135
-150
-165
Value
2400–2483.5 MHz
8 dBi
50 Ohms
13"
Omni-directional (360°)
100 MHz
<1.5:1
Linear vertical
50 ohms
Extruded bracket for mast mounting.
0.5 lb (0.226 kg)
20.2 in (513.1 mm)
Enterasys Wireless AP External Antenna Site Preparation and Installation Guide A-13
External Antennas for Use with Outdoor APs
0
-15
15
30
150
165
180
45
60
75
-20
90
105
120
135
