External Antennas for Use with Indoor APs

WS-ANT01

Specifications

Table A-26 WS-ANT01 Specifications
Specification
Frequency
Gain
VSWR
Polarization
Azimuth (3 dB beamwidth)
Input Impedance
Power
Dimensions

Radiation Patterns

Figure A-58
A-48 Antenna Specifications
Value
2.4-2.4835 GHz and 5.15-5.35 GHz
4 dBi @ 2.45 GHz
5 dBi @ 5.25 GHz
< 2.0
Linear Vertical
Omnidirectional
50 ohms
< 2.0 watts
130 mm x 21 mm

WS-ANT01 E-Plane 2.45 GHz
