Package Contents

Meter Overview

Indicator
A
L1, L2, L3
Voltage Phase Active Indicator
B
Run
Device Running Status Indicator
C
-
Infrared Communication Port
D
-
E
Comm.
F
Alarm
Alarm/Energy Pulse Indicator

LED Indicator

Indicator
Color
L1/L2/L3
Green
Run
Green
Alarm
Red
Green
Comm.

Mounting the Meter

Before installation, make sure that the DIN Rail is already in place
Move the installation clip at the back of the PMC-352-C downward to the "unlock"
position
Align the top of the mounting channel at the back of the PMC-352-C at an angle against
the top of the DIN Rail as shown in figure right
Rotate the bottom of the PMC-352-C towards the back while applying a slight pressure
to make sure that the device is completely and securely fixed on to the DIN Rail
Push the installation clip upward to the "lock" position to secure the PMC-352-C on to
the DIN Rail
PMC-352-C Quick Start Guide
a. PMC-352-C Meter with all installation clips and plug-in connectors installed
b. Factory Test Report
c. CD with PMC-352-C User Manual
d. Quick Start Guide (this document)
Description
Antenna
Communication Indicator
Status
On
Off
All Off
Blink once per second
Off
Flashing
On
Flashing
Off
Version 1.1
November 30, 2023
Terminal
G
TC11, TC12, TC21, TC22, TC31, TC32, TC41, TC42
H
DIC, DI1, DI2, DI3
I
J
I11, I12, I21, I22, I31, I32
K
V1, V2, V3, VN
L
L/+, N/- (NC, NC for Self-Powered option)
Register 6040 is enabled and the corresponding Voltage Phase is active
Register 6040 is enabled and the corresponding Voltage Phase is inactive
Power Off or Device is running abnormally
Energy Pulsing is disabled and at least one Setpoint is Active
Receiving or transmitting data via RS-485 or LoRa
D+, D-
Description
Register 6040 is disabled
Device is running normally
Energy Pulsing is enabled
No Communication
Revision Date: November 30, 2023
Description
NTC Inputs
Digital Inputs
RS-485 Ports
Current Inputs
Voltage Inputs
Power Supply
