Maxxus Multi-Trainer Pro Assembly Instructions Manual page 4

Part Description
5 "Hexagon socket button head bolt
M10x65"
6 washer Ø10
7 lock nut M10
8 "hexagon socket button head bolt
M10x70"
18 corrugated washer Ø10
20 hexagon socket button head bolt
M10x25
21 hexagon screw
M10x30
22 spring washer Ø10
23 curved washer Ø10
27 hexagon socket button head bolt
M8x40
28 washer Ø8
37 hexagon socket button head bolt
M8x25
38 hexagon socket button head bolt
M10x75
42 hexagon socket button head bolt
M8x20
Fixing Material
QTY
10
28
15
2
2
1
2
2
2
4
8
4
1
4
4
