Shadowspec Serenity™ Part Naming
When unpacking your Serenity umbrella please check you have all the correct parts pictured below before beginning
assembly. If any parts are missing please contact support@shadowspec.com to resolve.
You will need to refer back to this page so why not earmark it for quick reference whilst you're assembling your umbrella.
Figure B - Serenity Umbrella Parts
Top Cap
Gas Spring
Through Spar
Carriage
Serenity Mast
Also Included with Umbrella:
• Hex Key Set
• No. 17 Ring Spanner
Figure C - Frame Canopy Parts
Top Pivot Block
Spring Pivot
Shadowglide Button
Shadowglide
Handle
Top Pivot Block
Rib Support (long/short)
Rotation Lock Lever
Serenity Spigot
Main Spar
Gas Spring
Carriage
Upper Hub Assembly
Rib Tip with
Canopy Screws
Lower Hub
with LED Light
Upper Rib (long/short)
Through Spar
S-Bend Pivot
Upper Rib
(Log / Short)
Rib Tip
with Canopy Screw
Top Cap
Top Pivot Block
Gas Spring
Top Catch
Through Spar
Rotation Lock Lever
Security Lock Screw
Rotation Plate
Serenity Spigot
Upper Hub Assembly
Rib Support Lower Hub with
(Log / Short) LED Light
Main Spar
Mast Channel
