Stage 1 - Key Dimensions of Your Shadowspec Serenity™

As the Shadowspec Serenity is available to you in a variety of configurations, care must be taken to check the sizing of
your chosen umbrella in the following table.
Key Measurement Notes:
Free-Standing Base installations will add 165mm | 6'' to the height
Surface plates will add 12mm | 1/2'' to the height.
Adding Free-Standing Base wheels will add a further 45-80mm | 2-3'' to the height.
Figure A - Shadowspec Serenity Umbrella Dimensions
B
A
Diagram Legend
A
Ground to central frame hub when closed*
B
Total height to top of canopy*
C
Height of umbrella to top of mast cap*
D
Ground to central frame hub when open*
E
Ground to lower outer edge of canopy*
F
Centre of Spigot to outside edge of canopy
G
Diagonal from centre of mast to corner
Note: All sizings and conversions are +/- 2.5mm / 2/32'' and are subject to change without notice.
It is recommended for commerical installations that metric measurements are used for any umbrella spacing to ensure accuracy
6
C
F
G
2.5m 8'
860mm 2'10''
2900mm 9'6''
2908mm 9'6''
2130mm 7'0''
2222mm 7'3''
2646mm 8'8''
3742mm 12'3''
D
F
3.0m 10' 3.5m
620mm 2'1'' 1079mm
2824mm 9'3'' 2975mm
2908mm 9'6'' 2908mm
2054mm 6'9'' 2205mm
2219mm 7'3'' 2237mm
2973mm 9'10'' 3447mm
4205mm 13'10'' N/A
E
11' 4.0m 13'
3'7'' 866mm 2'10''
9'9'' 2899mm 9'6''
9'7'' 2908mm 9'6''
7'3'' 2128mm 7'0''
7'4'' 2172mm 7'2''
11'4'' 3923mm 12'10''
N/A N/A N/A
