Folding Mechanism

Hydraulic Cylinder
The olding mechanism relies on a hydraulic cylinder. This is lled with oil
and is under high pressure. If the cylinder is damaged, the safe folding of the
treadmill deck is no longer guaranteed. It must therefore be replaced without
fail before the treadmill deck is raised again.
This treadmill is equipped with a folding mechanism. To save space, fold the
treadmill deck up and down as follows:
Klick
Figure similar to the treadmill
Folding up the Treadmill Deck
Step 1:
Make sure that the deck incline level is at "0", switch the treadmill o at the
main switch and remove the mains plug from the socket.
CAUTION:
Never old up the treadmill deck without the incline in "0" position or without
switching it o.
Step 2:
Hold onto the rear end of the treadmill deck and lift it upwards.
Make sure that you are standing with your eet rmly on the ground.
Step 3:
Push up the deck until you hear it click into the catch.
Check that it is locked safely in the upright position by gently shaking the
deck.
