Max/Min Log Function - Time Electronics 7000 User Manual

Time Electronics
7000 RTD Calibrator
4.5

Max/Min Log Function

In Measure Mode the calibrator is able to log the measured maximum and minimum values.
The following assumes that the calibrator has already been set up for the correct connection,
measure mode, RTD type and range as described in Measure Mode Section 3.1.
To enter the Max/Min function press
•
The minimum input value will be recorded and displayed in the lower left-hand
•
corner of the display.
The maximum input value will be recorded and displayed in the lower right-hand
•
corner of the display.
The maximum and minimum values will be updated if a new high or low is reach
•
during the session.
• To exit the Max/Min function and clear the stored values press
15
User Manual
